Fix AD9361 digital interface tuning #35
Merged
Conversation
This file contains hidden or bidirectional Unicode text that may be interpreted or compiled differently than what appears below. To review, open the file in an editor that reveals hidden Unicode characters.
Learn more about bidirectional Unicode characters
mhennerich
approved these changes
Jan 23, 2018
commodo
reviewed
Jan 23, 2018
drivers/iio/adc/ad9361_conv.c
Outdated
| int i, j; | ||
|
|
||
| printk("SAMPL CLK: %lu tuning: %s\n", | ||
| printk(KERN_INFO "SAMPL CLK: %lu tuning: %s\n", |
Contributor
There was a problem hiding this comment.
would it make sense to use the convenience macros ?
pr_info() or pr_cont() ?
no strong preference from me whether to use them or leave this as is
Author
There was a problem hiding this comment.
makes sense, I didn't think about this, thanks.
mhennerich
approved these changes
Jan 23, 2018
commodo
reviewed
Jan 23, 2018
drivers/iio/adc/ad9361_conv.c
Outdated
| } | ||
|
|
||
| field[i][j] = ret; | ||
| field[j][i] = ret; |
Contributor
There was a problem hiding this comment.
curios: is this ok ? the row & col indexes have been switched
Author
There was a problem hiding this comment.
Yes, it is OK, the order in which they are passed to ad9361_set_intf_delay() was changed as well. This was done to avoid unnecessary transitions to the ALERT state.
dbogdan
approved these changes
Jan 23, 2018
Newer kernels require that a continued printk statement is prefixed with KERN_CONT, otherwise a newline will be inserted. Use the pr_info() and pr_cont() macros to print the diagnostic output to make sure that the proper message level indicators are used. Also get rid of the extra newline at the end of the output, we don't really need this. Signed-off-by: Lars-Peter Clausen <lars@metafoo.de>
When the feedback clock changes, either in phase or frequency, or any other discontinuities appear in the feedback clock, the AD9361 must go to the ALERT state. Otherwise an incorrect internal state might be entered and data on the transmit path might get corrupted. This issue is visible during interface tuning where the TX tuning can fail under certain circumstances. To avoid this issue make sure that the AD9361 is always in the ALERT state when changing the feedback clock during interface tuning. This makes sure that the interface tuning always succeeds if there is a valid delay setting that results in a working interface. Signed-off-by: Lars-Peter Clausen <lars@metafoo.de>
…e tuning
During digital interface tuning the relative delay between the clock and
data is sweep from the minimum to the maximum value and for each value it
is checked whether the interface works reliably or not.
Lets define the relative delay as clock delay - data delay.
Sweeping is done in two phases:
1) Clock delay is set to zero and data delay is incremented from 0 to 15.
This produces a relative delay from 0 to -15.
2) Data delay is set to zero and clock delay is incremented from 0 to 15.
This produces a relative delay of 0 to 15.
Changing the clock delay requires a transition to the ALERT state and back
to FDD state. This means during the second phase a lot of transitions are
required.
The same set of relative delay values can be produced by changing the
second phase so that clock delay is set to 15 and then data delay is
decremented from 15 to 0. This reduces the ALERT state transitions that are
necessary to 1.
Signed-off-by: Lars-Peter Clausen <lars@metafoo.de>
We have the same pattern to get the number of PHY channels in a few places. Add a helper function to replace the duplicated logic. Signed-off-by: Lars-Peter Clausen <lars@metafoo.de>
There are multiple places that have the same code to check the PN checker status. Consolidate those into a common helper function. This reduces code size and gives consistent behavior. Signed-off-by: Lars-Peter Clausen <lars@metafoo.de>
…ness
The ad9361_dig_tune() function is pretty difficult to follow at the moment,
it has many levels of nested conditional statements. The function also has
multiple exit paths which are mostly the same, but with minor differences
and bugs. E.g. not all exits paths properly restore the previous state of
the BIST setup.
Rework the ad9361_dig_tune() by breaking it into 3 sub-functions.
1) ad9361_dig_tune_delay() that does the actual interface tuning by
sweeping over all possible delay values.
2) ad9361_dig_tune_rx() that does the preparatory and cleanup work for RX
tuning.
3) ad9361_dig_tune_tx() that does the preparatory and cleanup work for TX
tuning.
ad9361_dig_tune() itself it left with general preparatory and cleanup work
for interface tuning and calling ad9361_dig_tune_rx() and ad9361_dig_tune_tx().
The function also only has a single exit path now to ensure that it
correctly cleans up in all cases.
Signed-off-by: Lars-Peter Clausen <lars@metafoo.de>
For diagnostic purposes it is useful to highlight the selected clock or data delay. Indicate the chosen delay in the diagnostic by a 'O' character. Signed-off-by: Lars-Peter Clausen <lars@metafoo.de>
…eanup Make sure that all timing analysis relevant configuration parameters have the right value. E.g. currently bist timing analysis does not work in TDD mode or when loopback mode is enabled. Also make sure to restore all configuration parameters to their previous value after the timing analysis has completed. Signed-off-by: Lars-Peter Clausen <lars@metafoo.de>
lclausen-adi
force-pushed
the
ad9361_fix_tune
branch
from
0fa1a63 to
8277d20
Compare
Contributor
|
commits but, other than that, LGTM :) |
Author
|
Yeah, but that's because the existing code is quite messy. Future patches should be easier to follow with things being a bit cleaner now. |
commodo
pushed a commit
that referenced
this pull request
Sep 10, 2020
In the existing NVMeOF Passthru core command handling on failure of nvme_alloc_request() it errors out with rq value set to NULL. In the error handling path it calls blk_put_request() without checking if rq is set to NULL or not which produces following Oops:- [ 1457.346861] BUG: kernel NULL pointer dereference, address: 0000000000000000 [ 1457.347838] #PF: supervisor read access in kernel mode [ 1457.348464] #PF: error_code(0x0000) - not-present page [ 1457.349085] PGD 0 P4D 0 [ 1457.349402] Oops: 0000 [#1] SMP NOPTI [ 1457.349851] CPU: 18 PID: 10782 Comm: kworker/18:2 Tainted: G OE 5.8.0-rc4nvme-5.9+ #35 [ 1457.350951] Hardware name: QEMU Standard PC (i440FX + PIIX, 1996), BIOS rel-1.12.0-59-gc9ba5276e3214 [ 1457.352347] Workqueue: events nvme_loop_execute_work [nvme_loop] [ 1457.353062] RIP: 0010:blk_mq_free_request+0xe/0x110 [ 1457.353651] Code: 3f ff ff ff 83 f8 01 75 0d 4c 89 e7 e8 1b db ff ff e9 2d ff ff ff 0f 0b eb ef 66 8 [ 1457.355975] RSP: 0018:ffffc900035b7de0 EFLAGS: 00010282 [ 1457.356636] RAX: 0000000000000000 RBX: 0000000000000000 RCX: 0000000000000002 [ 1457.357526] RDX: ffffffffa060bd05 RSI: 0000000000000000 RDI: 0000000000000000 [ 1457.358416] RBP: 0000000000000037 R08: 0000000000000000 R09: 0000000000000000 [ 1457.359317] R10: 0000000000000000 R11: 000000000000006d R12: 0000000000000000 [ 1457.360424] R13: ffff8887ffa68600 R14: 0000000000000000 R15: ffff8888150564c8 [ 1457.361322] FS: 0000000000000000(0000) GS:ffff888814600000(0000) knlGS:0000000000000000 [ 1457.362337] CS: 0010 DS: 0000 ES: 0000 CR0: 0000000080050033 [ 1457.363058] CR2: 0000000000000000 CR3: 000000081c0ac000 CR4: 00000000003406e0 [ 1457.363973] Call Trace: [ 1457.364296] nvmet_passthru_execute_cmd+0x150/0x2c0 [nvmet] [ 1457.364990] process_one_work+0x24e/0x5a0 [ 1457.365493] ? __schedule+0x353/0x840 [ 1457.365957] worker_thread+0x3c/0x380 [ 1457.366426] ? process_one_work+0x5a0/0x5a0 [ 1457.366948] kthread+0x135/0x150 [ 1457.367362] ? kthread_create_on_node+0x60/0x60 [ 1457.367934] ret_from_fork+0x22/0x30 [ 1457.368388] Modules linked in: nvme_loop(OE) nvmet(OE) nvme_fabrics(OE) null_blk nvme(OE) nvme_corer [ 1457.368414] ata_piix crc32c_intel virtio_pci libata virtio_ring serio_raw t10_pi virtio floppy dm_] [ 1457.380849] CR2: 0000000000000000 [ 1457.381288] ---[ end trace c6cab61bfd1f68fd ]--- [ 1457.381861] RIP: 0010:blk_mq_free_request+0xe/0x110 [ 1457.382469] Code: 3f ff ff ff 83 f8 01 75 0d 4c 89 e7 e8 1b db ff ff e9 2d ff ff ff 0f 0b eb ef 66 8 [ 1457.384749] RSP: 0018:ffffc900035b7de0 EFLAGS: 00010282 [ 1457.385393] RAX: 0000000000000000 RBX: 0000000000000000 RCX: 0000000000000002 [ 1457.386264] RDX: ffffffffa060bd05 RSI: 0000000000000000 RDI: 0000000000000000 [ 1457.387142] RBP: 0000000000000037 R08: 0000000000000000 R09: 0000000000000000 [ 1457.388029] R10: 0000000000000000 R11: 000000000000006d R12: 0000000000000000 [ 1457.388914] R13: ffff8887ffa68600 R14: 0000000000000000 R15: ffff8888150564c8 [ 1457.389798] FS: 0000000000000000(0000) GS:ffff888814600000(0000) knlGS:0000000000000000 [ 1457.390796] CS: 0010 DS: 0000 ES: 0000 CR0: 0000000080050033 [ 1457.391508] CR2: 0000000000000000 CR3: 000000081c0ac000 CR4: 00000000003406e0 [ 1457.392525] Kernel panic - not syncing: Fatal exception [ 1457.394138] Kernel Offset: disabled [ 1457.394677] ---[ end Kernel panic - not syncing: Fatal exception ]--- We fix this Oops by adding a new goto label out_put_req and reordering the blk_put_request call to avoid calling blk_put_request() with rq value is set to NULL. Here we also update the rest of the code accordingly. Fixes: 06b7164dfdc0 ("nvmet: add passthru code to process commands") Signed-off-by: Chaitanya Kulkarni <chaitanya.kulkarni@wdc.com> Reviewed-by: Logan Gunthorpe <logang@deltatee.com> Signed-off-by: Sagi Grimberg <sagi@grimberg.me> Signed-off-by: Jens Axboe <axboe@kernel.dk>
machschmitt
pushed a commit
to machschmitt/linux
that referenced
this pull request
Mar 27, 2025
Use raw_spinlock in order to fix spurious messages about invalid context
when spinlock debugging is enabled. The lock is only used to serialize
register access.
[ 4.239592] =============================
[ 4.239595] [ BUG: Invalid wait context ]
[ 4.239599] 6.13.0-rc7-arm64-renesas-05496-gd088502a519f analogdevicesinc#35 Not tainted
[ 4.239603] -----------------------------
[ 4.239606] kworker/u8:5/76 is trying to lock:
[ 4.239609] ffff0000091898a0 (&p->lock){....}-{3:3}, at: gpio_rcar_config_interrupt_input_mode+0x34/0x164
[ 4.239641] other info that might help us debug this:
[ 4.239643] context-{5:5}
[ 4.239646] 5 locks held by kworker/u8:5/76:
[ 4.239651] #0: ffff0000080fb148 ((wq_completion)async){+.+.}-{0:0}, at: process_one_work+0x190/0x62c
[ 4.250180] OF: /soc/sound@ec500000/ports/port@0/endpoint: Read of boolean property 'frame-master' with a value.
[ 4.254094] #1: ffff80008299bd80 ((work_completion)(&entry->work)){+.+.}-{0:0}, at: process_one_work+0x1b8/0x62c
[ 4.254109] #2: ffff00000920c8f8
[ 4.258345] OF: /soc/sound@ec500000/ports/port@1/endpoint: Read of boolean property 'bitclock-master' with a value.
[ 4.264803] (&dev->mutex){....}-{4:4}, at: __device_attach_async_helper+0x3c/0xdc
[ 4.264820] analogdevicesinc#3: ffff00000a50ca40 (request_class#2){+.+.}-{4:4}, at: __setup_irq+0xa0/0x690
[ 4.264840] analogdevicesinc#4:
[ 4.268872] OF: /soc/sound@ec500000/ports/port@1/endpoint: Read of boolean property 'frame-master' with a value.
[ 4.273275] ffff00000a50c8c8 (lock_class){....}-{2:2}, at: __setup_irq+0xc4/0x690
[ 4.296130] renesas_sdhi_internal_dmac ee100000.mmc: mmc1 base at 0x00000000ee100000, max clock rate 200 MHz
[ 4.304082] stack backtrace:
[ 4.304086] CPU: 1 UID: 0 PID: 76 Comm: kworker/u8:5 Not tainted 6.13.0-rc7-arm64-renesas-05496-gd088502a519f analogdevicesinc#35
[ 4.304092] Hardware name: Renesas Salvator-X 2nd version board based on r8a77965 (DT)
[ 4.304097] Workqueue: async async_run_entry_fn
[ 4.304106] Call trace:
[ 4.304110] show_stack+0x14/0x20 (C)
[ 4.304122] dump_stack_lvl+0x6c/0x90
[ 4.304131] dump_stack+0x14/0x1c
[ 4.304138] __lock_acquire+0xdfc/0x1584
[ 4.426274] lock_acquire+0x1c4/0x33c
[ 4.429942] _raw_spin_lock_irqsave+0x5c/0x80
[ 4.434307] gpio_rcar_config_interrupt_input_mode+0x34/0x164
[ 4.440061] gpio_rcar_irq_set_type+0xd4/0xd8
[ 4.444422] __irq_set_trigger+0x5c/0x178
[ 4.448435] __setup_irq+0x2e4/0x690
[ 4.452012] request_threaded_irq+0xc4/0x190
[ 4.456285] devm_request_threaded_irq+0x7c/0xf4
[ 4.459398] ata1: link resume succeeded after 1 retries
[ 4.460902] mmc_gpiod_request_cd_irq+0x68/0xe0
[ 4.470660] mmc_start_host+0x50/0xac
[ 4.474327] mmc_add_host+0x80/0xe4
[ 4.477817] tmio_mmc_host_probe+0x2b0/0x440
[ 4.482094] renesas_sdhi_probe+0x488/0x6f4
[ 4.486281] renesas_sdhi_internal_dmac_probe+0x60/0x78
[ 4.491509] platform_probe+0x64/0xd8
[ 4.495178] really_probe+0xb8/0x2a8
[ 4.498756] __driver_probe_device+0x74/0x118
[ 4.503116] driver_probe_device+0x3c/0x154
[ 4.507303] __device_attach_driver+0xd4/0x160
[ 4.511750] bus_for_each_drv+0x84/0xe0
[ 4.515588] __device_attach_async_helper+0xb0/0xdc
[ 4.520470] async_run_entry_fn+0x30/0xd8
[ 4.524481] process_one_work+0x210/0x62c
[ 4.528494] worker_thread+0x1ac/0x340
[ 4.532245] kthread+0x10c/0x110
[ 4.535476] ret_from_fork+0x10/0x20
Signed-off-by: Niklas Söderlund <niklas.soderlund+renesas@ragnatech.se>
Reviewed-by: Geert Uytterhoeven <geert+renesas@glider.be>
Tested-by: Geert Uytterhoeven <geert+renesas@glider.be>
Cc: stable@vger.kernel.org
Link: https://lore.kernel.org/r/20250121135833.3769310-1-niklas.soderlund+renesas@ragnatech.se
Signed-off-by: Bartosz Golaszewski <bartosz.golaszewski@linaro.org>
nunojsa
pushed a commit
that referenced
this pull request
Aug 5, 2025
[ Upstream commit eedf3e3 ] ACPICA commit 1c28da2242783579d59767617121035dafba18c3 This was originally done in NetBSD: NetBSD/src@b69d1ac and is the correct alternative to the smattering of `memcpy`s I previously contributed to this repository. This also sidesteps the newly strict checks added in UBSAN: llvm/llvm-project@7926744 Before this change we see the following UBSAN stack trace in Fuchsia: #0 0x000021afcfdeca5e in acpi_rs_get_address_common(struct acpi_resource*, union aml_resource*) ../../third_party/acpica/source/components/resources/rsaddr.c:329 <platform-bus-x86.so>+0x6aca5e #1.2 0x000021982bc4af3c in ubsan_get_stack_trace() compiler-rt/lib/ubsan/ubsan_diag.cpp:41 <libclang_rt.asan.so>+0x41f3c #1.1 0x000021982bc4af3c in maybe_print_stack_trace() compiler-rt/lib/ubsan/ubsan_diag.cpp:51 <libclang_rt.asan.so>+0x41f3c #1 0x000021982bc4af3c in ~scoped_report() compiler-rt/lib/ubsan/ubsan_diag.cpp:395 <libclang_rt.asan.so>+0x41f3c #2 0x000021982bc4bb6f in handletype_mismatch_impl() compiler-rt/lib/ubsan/ubsan_handlers.cpp:137 <libclang_rt.asan.so>+0x42b6f #3 0x000021982bc4b723 in __ubsan_handle_type_mismatch_v1 compiler-rt/lib/ubsan/ubsan_handlers.cpp:142 <libclang_rt.asan.so>+0x42723 #4 0x000021afcfdeca5e in acpi_rs_get_address_common(struct acpi_resource*, union aml_resource*) ../../third_party/acpica/source/components/resources/rsaddr.c:329 <platform-bus-x86.so>+0x6aca5e #5 0x000021afcfdf2089 in acpi_rs_convert_aml_to_resource(struct acpi_resource*, union aml_resource*, struct acpi_rsconvert_info*) ../../third_party/acpica/source/components/resources/rsmisc.c:355 <platform-bus-x86.so>+0x6b2089 #6 0x000021afcfded169 in acpi_rs_convert_aml_to_resources(u8*, u32, u32, u8, void**) ../../third_party/acpica/source/components/resources/rslist.c:137 <platform-bus-x86.so>+0x6ad169 #7 0x000021afcfe2d24a in acpi_ut_walk_aml_resources(struct acpi_walk_state*, u8*, acpi_size, acpi_walk_aml_callback, void**) ../../third_party/acpica/source/components/utilities/utresrc.c:237 <platform-bus-x86.so>+0x6ed24a #8 0x000021afcfde66b7 in acpi_rs_create_resource_list(union acpi_operand_object*, struct acpi_buffer*) ../../third_party/acpica/source/components/resources/rscreate.c:199 <platform-bus-x86.so>+0x6a66b7 #9 0x000021afcfdf6979 in acpi_rs_get_method_data(acpi_handle, const char*, struct acpi_buffer*) ../../third_party/acpica/source/components/resources/rsutils.c:770 <platform-bus-x86.so>+0x6b6979 #10 0x000021afcfdf708f in acpi_walk_resources(acpi_handle, char*, acpi_walk_resource_callback, void*) ../../third_party/acpica/source/components/resources/rsxface.c:731 <platform-bus-x86.so>+0x6b708f #11 0x000021afcfa95dcf in acpi::acpi_impl::walk_resources(acpi::acpi_impl*, acpi_handle, const char*, acpi::Acpi::resources_callable) ../../src/devices/board/lib/acpi/acpi-impl.cc:41 <platform-bus-x86.so>+0x355dcf #12 0x000021afcfaa8278 in acpi::device_builder::gather_resources(acpi::device_builder*, acpi::Acpi*, fidl::any_arena&, acpi::Manager*, acpi::device_builder::gather_resources_callback) ../../src/devices/board/lib/acpi/device-builder.cc:84 <platform-bus-x86.so>+0x368278 #13 0x000021afcfbddb87 in acpi::Manager::configure_discovered_devices(acpi::Manager*) ../../src/devices/board/lib/acpi/manager.cc:75 <platform-bus-x86.so>+0x49db87 #14 0x000021afcf99091d in publish_acpi_devices(acpi::Manager*, zx_device_t*, zx_device_t*) ../../src/devices/board/drivers/x86/acpi-nswalk.cc:95 <platform-bus-x86.so>+0x25091d #15 0x000021afcf9c1d4e in x86::X86::do_init(x86::X86*) ../../src/devices/board/drivers/x86/x86.cc:60 <platform-bus-x86.so>+0x281d4e #16 0x000021afcf9e33ad in λ(x86::X86::ddk_init::(anon class)*) ../../src/devices/board/drivers/x86/x86.cc:77 <platform-bus-x86.so>+0x2a33ad #17 0x000021afcf9e313e in fit::internal::target<(lambda at../../src/devices/board/drivers/x86/x86.cc:76:19), false, false, std::__2::allocator<std::byte>, void>::invoke(void*) ../../sdk/lib/fit/include/lib/fit/internal/function.h:183 <platform-bus-x86.so>+0x2a313e #18 0x000021afcfbab4c7 in fit::internal::function_base<16UL, false, void(), std::__2::allocator<std::byte>>::invoke(const fit::internal::function_base<16UL, false, void (), std::__2::allocator<std::byte> >*) ../../sdk/lib/fit/include/lib/fit/internal/function.h:522 <platform-bus-x86.so>+0x46b4c7 #19 0x000021afcfbab342 in fit::function_impl<16UL, false, void(), std::__2::allocator<std::byte>>::operator()(const fit::function_impl<16UL, false, void (), std::__2::allocator<std::byte> >*) ../../sdk/lib/fit/include/lib/fit/function.h:315 <platform-bus-x86.so>+0x46b342 #20 0x000021afcfcd98c3 in async::internal::retained_task::Handler(async_dispatcher_t*, async_task_t*, zx_status_t) ../../sdk/lib/async/task.cc:24 <platform-bus-x86.so>+0x5998c3 #21 0x00002290f9924616 in λ(const driver_runtime::Dispatcher::post_task::(anon class)*, std::__2::unique_ptr<driver_runtime::callback_request, std::__2::default_delete<driver_runtime::callback_request> >, zx_status_t) ../../src/devices/bin/driver_runtime/dispatcher.cc:789 <libdriver_runtime.so>+0x10a616 #22 0x00002290f9924323 in fit::internal::target<(lambda at../../src/devices/bin/driver_runtime/dispatcher.cc:788:7), true, false, std::__2::allocator<std::byte>, void, std::__2::unique_ptr<driver_runtime::callback_request, std::__2::default_delete<driver_runtime::callback_request>>, int>::invoke(void*, std::__2::unique_ptr<driver_runtime::callback_request, std::__2::default_delete<driver_runtime::callback_request> >, int) ../../sdk/lib/fit/include/lib/fit/internal/function.h:128 <libdriver_runtime.so>+0x10a323 #23 0x00002290f9904b76 in fit::internal::function_base<24UL, true, void(std::__2::unique_ptr<driver_runtime::callback_request, std::__2::default_delete<driver_runtime::callback_request>>, int), std::__2::allocator<std::byte>>::invoke(const fit::internal::function_base<24UL, true, void (std::__2::unique_ptr<driver_runtime::callback_request, std::__2::default_delete<driver_runtime::callback_request> >, int), std::__2::allocator<std::byte> >*, std::__2::unique_ptr<driver_runtime::callback_request, std::__2::default_delete<driver_runtime::callback_request> >, int) ../../sdk/lib/fit/include/lib/fit/internal/function.h:522 <libdriver_runtime.so>+0xeab76 #24 0x00002290f9904831 in fit::callback_impl<24UL, true, void(std::__2::unique_ptr<driver_runtime::callback_request, std::__2::default_delete<driver_runtime::callback_request>>, int), std::__2::allocator<std::byte>>::operator()(fit::callback_impl<24UL, true, void (std::__2::unique_ptr<driver_runtime::callback_request, std::__2::default_delete<driver_runtime::callback_request> >, int), std::__2::allocator<std::byte> >*, std::__2::unique_ptr<driver_runtime::callback_request, std::__2::default_delete<driver_runtime::callback_request> >, int) ../../sdk/lib/fit/include/lib/fit/function.h:471 <libdriver_runtime.so>+0xea831 #25 0x00002290f98d5adc in driver_runtime::callback_request::Call(driver_runtime::callback_request*, std::__2::unique_ptr<driver_runtime::callback_request, std::__2::default_delete<driver_runtime::callback_request> >, zx_status_t) ../../src/devices/bin/driver_runtime/callback_request.h:74 <libdriver_runtime.so>+0xbbadc #26 0x00002290f98e1e58 in driver_runtime::Dispatcher::dispatch_callback(driver_runtime::Dispatcher*, std::__2::unique_ptr<driver_runtime::callback_request, std::__2::default_delete<driver_runtime::callback_request> >) ../../src/devices/bin/driver_runtime/dispatcher.cc:1248 <libdriver_runtime.so>+0xc7e58 #27 0x00002290f98e4159 in driver_runtime::Dispatcher::dispatch_callbacks(driver_runtime::Dispatcher*, std::__2::unique_ptr<driver_runtime::Dispatcher::event_waiter, std::__2::default_delete<driver_runtime::Dispatcher::event_waiter> >, fbl::ref_ptr<driver_runtime::Dispatcher>) ../../src/devices/bin/driver_runtime/dispatcher.cc:1308 <libdriver_runtime.so>+0xca159 #28 0x00002290f9918414 in λ(const driver_runtime::Dispatcher::create_with_adder::(anon class)*, std::__2::unique_ptr<driver_runtime::Dispatcher::event_waiter, std::__2::default_delete<driver_runtime::Dispatcher::event_waiter> >, fbl::ref_ptr<driver_runtime::Dispatcher>) ../../src/devices/bin/driver_runtime/dispatcher.cc:353 <libdriver_runtime.so>+0xfe414 #29 0x00002290f991812d in fit::internal::target<(lambda at../../src/devices/bin/driver_runtime/dispatcher.cc:351:7), true, false, std::__2::allocator<std::byte>, void, std::__2::unique_ptr<driver_runtime::Dispatcher::event_waiter, std::__2::default_delete<driver_runtime::Dispatcher::event_waiter>>, fbl::ref_ptr<driver_runtime::Dispatcher>>::invoke(void*, std::__2::unique_ptr<driver_runtime::Dispatcher::event_waiter, std::__2::default_delete<driver_runtime::Dispatcher::event_waiter> >, fbl::ref_ptr<driver_runtime::Dispatcher>) ../../sdk/lib/fit/include/lib/fit/internal/function.h:128 <libdriver_runtime.so>+0xfe12d #30 0x00002290f9906fc7 in fit::internal::function_base<8UL, true, void(std::__2::unique_ptr<driver_runtime::Dispatcher::event_waiter, std::__2::default_delete<driver_runtime::Dispatcher::event_waiter>>, fbl::ref_ptr<driver_runtime::Dispatcher>), std::__2::allocator<std::byte>>::invoke(const fit::internal::function_base<8UL, true, void (std::__2::unique_ptr<driver_runtime::Dispatcher::event_waiter, std::__2::default_delete<driver_runtime::Dispatcher::event_waiter> >, fbl::ref_ptr<driver_runtime::Dispatcher>), std::__2::allocator<std::byte> >*, std::__2::unique_ptr<driver_runtime::Dispatcher::event_waiter, std::__2::default_delete<driver_runtime::Dispatcher::event_waiter> >, fbl::ref_ptr<driver_runtime::Dispatcher>) ../../sdk/lib/fit/include/lib/fit/internal/function.h:522 <libdriver_runtime.so>+0xecfc7 #31 0x00002290f9906c66 in fit::function_impl<8UL, true, void(std::__2::unique_ptr<driver_runtime::Dispatcher::event_waiter, std::__2::default_delete<driver_runtime::Dispatcher::event_waiter>>, fbl::ref_ptr<driver_runtime::Dispatcher>), std::__2::allocator<std::byte>>::operator()(const fit::function_impl<8UL, true, void (std::__2::unique_ptr<driver_runtime::Dispatcher::event_waiter, std::__2::default_delete<driver_runtime::Dispatcher::event_waiter> >, fbl::ref_ptr<driver_runtime::Dispatcher>), std::__2::allocator<std::byte> >*, std::__2::unique_ptr<driver_runtime::Dispatcher::event_waiter, std::__2::default_delete<driver_runtime::Dispatcher::event_waiter> >, fbl::ref_ptr<driver_runtime::Dispatcher>) ../../sdk/lib/fit/include/lib/fit/function.h:315 <libdriver_runtime.so>+0xecc66 #32 0x00002290f98e73d9 in driver_runtime::Dispatcher::event_waiter::invoke_callback(driver_runtime::Dispatcher::event_waiter*, std::__2::unique_ptr<driver_runtime::Dispatcher::event_waiter, std::__2::default_delete<driver_runtime::Dispatcher::event_waiter> >, fbl::ref_ptr<driver_runtime::Dispatcher>) ../../src/devices/bin/driver_runtime/dispatcher.h:543 <libdriver_runtime.so>+0xcd3d9 #33 0x00002290f98e700d in driver_runtime::Dispatcher::event_waiter::handle_event(std::__2::unique_ptr<driver_runtime::Dispatcher::event_waiter, std::__2::default_delete<driver_runtime::Dispatcher::event_waiter> >, async_dispatcher_t*, async::wait_base*, zx_status_t, zx_packet_signal_t const*) ../../src/devices/bin/driver_runtime/dispatcher.cc:1442 <libdriver_runtime.so>+0xcd00d #34 0x00002290f9918983 in async_loop_owned_event_handler<driver_runtime::Dispatcher::event_waiter>::handle_event(async_loop_owned_event_handler<driver_runtime::Dispatcher::event_waiter>*, async_dispatcher_t*, async::wait_base*, zx_status_t, zx_packet_signal_t const*) ../../src/devices/bin/driver_runtime/async_loop_owned_event_handler.h:59 <libdriver_runtime.so>+0xfe983 #35 0x00002290f9918b9e in async::wait_method<async_loop_owned_event_handler<driver_runtime::Dispatcher::event_waiter>, &async_loop_owned_event_handler<driver_runtime::Dispatcher::event_waiter>::handle_event>::call_handler(async_dispatcher_t*, async_wait_t*, zx_status_t, zx_packet_signal_t const*) ../../sdk/lib/async/include/lib/async/cpp/wait.h:201 <libdriver_runtime.so>+0xfeb9e #36 0x00002290f99bf509 in async_loop_dispatch_wait(async_loop_t*, async_wait_t*, zx_status_t, zx_packet_signal_t const*) ../../sdk/lib/async-loop/loop.c:394 <libdriver_runtime.so>+0x1a5509 #37 0x00002290f99b9958 in async_loop_run_once(async_loop_t*, zx_time_t) ../../sdk/lib/async-loop/loop.c:343 <libdriver_runtime.so>+0x19f958 #38 0x00002290f99b9247 in async_loop_run(async_loop_t*, zx_time_t, _Bool) ../../sdk/lib/async-loop/loop.c:301 <libdriver_runtime.so>+0x19f247 #39 0x00002290f99ba962 in async_loop_run_thread(void*) ../../sdk/lib/async-loop/loop.c:860 <libdriver_runtime.so>+0x1a0962 #40 0x000041afd176ef30 in start_c11(void*) ../../zircon/third_party/ulib/musl/pthread/pthread_create.c:63 <libc.so>+0x84f30 #41 0x000041afd18a448d in thread_trampoline(uintptr_t, uintptr_t) ../../zircon/system/ulib/runtime/thread.cc:100 <libc.so>+0x1ba48d Link: acpica/acpica@1c28da22 Signed-off-by: Rafael J. Wysocki <rafael.j.wysocki@intel.com> Link: https://patch.msgid.link/4664267.LvFx2qVVIh@rjwysocki.net Signed-off-by: Tamir Duberstein <tamird@gmail.com> [ rjw: Pick up the tag from Tamir ] Signed-off-by: Rafael J. Wysocki <rafael.j.wysocki@intel.com> Signed-off-by: Sasha Levin <sashal@kernel.org>
github-actions bot
pushed a commit
that referenced
this pull request
Sep 5, 2025
Patch series "mm: remove nth_page()", v2. As discussed recently with Linus, nth_page() is just nasty and we would like to remove it. To recap, the reason we currently need nth_page() within a folio is because on some kernel configs (SPARSEMEM without SPARSEMEM_VMEMMAP), the memmap is allocated per memory section. While buddy allocations cannot cross memory section boundaries, hugetlb and dax folios can. So crossing a memory section means that "page++" could do the wrong thing. Instead, nth_page() on these problematic configs always goes from page->pfn, to the go from (++pfn)->page, which is rather nasty. Likely, many people have no idea when nth_page() is required and when it might be dropped. We refer to such problematic PFN ranges and "non-contiguous pages". If we only deal with "contiguous pages", there is not need for nth_page(). Besides that "obvious" folio case, we might end up using nth_page() within CMA allocations (again, could span memory sections), and in one corner case (kfence) when processing memblock allocations (again, could span memory sections). So let's handle all that, add sanity checks, and remove nth_page(). Patch #1 -> #5 : stop making SPARSEMEM_VMEMMAP user-selectable + cleanups Patch #6 -> #13 : disallow folios to have non-contiguous pages Patch #14 -> #20 : remove nth_page() usage within folios Patch #22 : disallow CMA allocations of non-contiguous pages Patch #23 -> #33 : sanity+check + remove nth_page() usage within SG entry Patch #34 : sanity-check + remove nth_page() usage in unpin_user_page_range_dirty_lock() Patch #35 : remove nth_page() in kfence Patch #36 : adjust stale comment regarding nth_page Patch #37 : mm: remove nth_page() A lot of this is inspired from the discussion at [1] between Linus, Jason and me, so cudos to them. This patch (of 37): In an ideal world, we wouldn't have to deal with SPARSEMEM without SPARSEMEM_VMEMMAP, but in particular for 32bit SPARSEMEM_VMEMMAP is considered too costly and consequently not supported. However, if an architecture does support SPARSEMEM with SPARSEMEM_VMEMMAP, let's forbid the user to disable VMEMMAP: just like we already do for arm64, s390 and x86. So if SPARSEMEM_VMEMMAP is supported, don't allow to use SPARSEMEM without SPARSEMEM_VMEMMAP. This implies that the option to not use SPARSEMEM_VMEMMAP will now be gone for loongarch, powerpc, riscv and sparc. All architectures only enable SPARSEMEM_VMEMMAP with 64bit support, so there should not really be a big downside to using the VMEMMAP (quite the contrary). This is a preparation for not supporting (1) folio sizes that exceed a single memory section (2) CMA allocations of non-contiguous page ranges in SPARSEMEM without SPARSEMEM_VMEMMAP configs, whereby we want to limit possible impact as much as possible (e.g., gigantic hugetlb page allocations suddenly fails). Link: https://lkml.kernel.org/r/20250901150359.867252-1-david@redhat.com Link: https://lkml.kernel.org/r/20250901150359.867252-2-david@redhat.com Link: https://lore.kernel.org/all/CAHk-=wiCYfNp4AJLBORU-c7ZyRBUp66W2-Et6cdQ4REx-GyQ_A@mail.gmail.com/T/#u [1] Signed-off-by: David Hildenbrand <david@redhat.com> Acked-by: Zi Yan <ziy@nvidia.com> Acked-by: Mike Rapoport (Microsoft) <rppt@kernel.org> Acked-by: SeongJae Park <sj@kernel.org> Reviewed-by: Wei Yang <richard.weiyang@gmail.com> Reviewed-by: Lorenzo Stoakes <lorenzo.stoakes@oracle.com> Reviewed-by: Liam R. Howlett <Liam.Howlett@oracle.com> Cc: Huacai Chen <chenhuacai@kernel.org> Cc: WANG Xuerui <kernel@xen0n.name> Cc: Madhavan Srinivasan <maddy@linux.ibm.com> Cc: Michael Ellerman <mpe@ellerman.id.au> Cc: Nicholas Piggin <npiggin@gmail.com> Cc: Christophe Leroy <christophe.leroy@csgroup.eu> Cc: Paul Walmsley <paul.walmsley@sifive.com> Cc: Palmer Dabbelt <palmer@dabbelt.com> Cc: Albert Ou <aou@eecs.berkeley.edu> Cc: Alexandre Ghiti <alex@ghiti.fr> Cc: "David S. Miller" <davem@davemloft.net> Cc: Andreas Larsson <andreas@gaisler.com> Cc: Alexander Gordeev <agordeev@linux.ibm.com> Cc: Alexander Potapenko <glider@google.com> Cc: Alexandru Elisei <alexandru.elisei@arm.com> Cc: Alex Dubov <oakad@yahoo.com> Cc: Alex Willamson <alex.williamson@redhat.com> Cc: Bart van Assche <bvanassche@acm.org> Cc: Borislav Betkov <bp@alien8.de> Cc: Brendan Jackman <jackmanb@google.com> Cc: Brett Creeley <brett.creeley@amd.com> Cc: Catalin Marinas <catalin.marinas@arm.com> Cc: Christian Borntraeger <borntraeger@linux.ibm.com> Cc: Christoph Lameter (Ampere) <cl@gentwo.org> Cc: Damien Le Maol <dlemoal@kernel.org> Cc: Dave Airlie <airlied@gmail.com> Cc: Dennis Zhou <dennis@kernel.org> Cc: Dmitriy Vyukov <dvyukov@google.com> Cc: Doug Gilbert <dgilbert@interlog.com> Cc: Heiko Carstens <hca@linux.ibm.com> Cc: Herbert Xu <herbert@gondor.apana.org.au> Cc: Ingo Molnar <mingo@redhat.com> Cc: Inki Dae <m.szyprowski@samsung.com> Cc: James Bottomley <james.bottomley@HansenPartnership.com> Cc: Jani Nikula <jani.nikula@linux.intel.com> Cc: Jason A. Donenfeld <jason@zx2c4.com> Cc: Jason Gunthorpe <jgg@nvidia.com> Cc: Jason Gunthorpe <jgg@ziepe.ca> Cc: Jens Axboe <axboe@kernel.dk> Cc: Jesper Nilsson <jesper.nilsson@axis.com> Cc: Johannes Weiner <hannes@cmpxchg.org> Cc: John Hubbard <jhubbard@nvidia.com> Cc: Jonas Lahtinen <joonas.lahtinen@linux.intel.com> Cc: Kevin Tian <kevin.tian@intel.com> Cc: Lars Persson <lars.persson@axis.com> Cc: Linus Torvalds <torvalds@linux-foundation.org> Cc: Marco Elver <elver@google.com> Cc: "Martin K. Petersen" <martin.petersen@oracle.com> Cc: Maxim Levitky <maximlevitsky@gmail.com> Cc: Michal Hocko <mhocko@suse.com> Cc: Muchun Song <muchun.song@linux.dev> Cc: Niklas Cassel <cassel@kernel.org> Cc: Oscar Salvador <osalvador@suse.de> Cc: Pavel Begunkov <asml.silence@gmail.com> Cc: Peter Xu <peterx@redhat.com> Cc: Robin Murohy <robin.murphy@arm.com> Cc: Rodrigo Vivi <rodrigo.vivi@intel.com> Cc: Shameerali Kolothum Thodi <shameerali.kolothum.thodi@huawei.com> Cc: Shuah Khan <shuah@kernel.org> Cc: Suren Baghdasaryan <surenb@google.com> Cc: Sven Schnelle <svens@linux.ibm.com> Cc: Tejun Heo <tj@kernel.org> Cc: Thomas Bogendoerfer <tsbogend@alpha.franken.de> Cc: Thomas Gleinxer <tglx@linutronix.de> Cc: Tvrtko Ursulin <tursulin@ursulin.net> Cc: Ulf Hansson <ulf.hansson@linaro.org> Cc: Vasily Gorbik <gor@linux.ibm.com> Cc: Vlastimil Babka <vbabka@suse.cz> Cc: Will Deacon <will@kernel.org> Cc: Yishai Hadas <yishaih@nvidia.com> Signed-off-by: Andrew Morton <akpm@linux-foundation.org>
github-actions bot
pushed a commit
that referenced
this pull request
Sep 6, 2025
Patch series "mm: remove nth_page()", v2. As discussed recently with Linus, nth_page() is just nasty and we would like to remove it. To recap, the reason we currently need nth_page() within a folio is because on some kernel configs (SPARSEMEM without SPARSEMEM_VMEMMAP), the memmap is allocated per memory section. While buddy allocations cannot cross memory section boundaries, hugetlb and dax folios can. So crossing a memory section means that "page++" could do the wrong thing. Instead, nth_page() on these problematic configs always goes from page->pfn, to the go from (++pfn)->page, which is rather nasty. Likely, many people have no idea when nth_page() is required and when it might be dropped. We refer to such problematic PFN ranges and "non-contiguous pages". If we only deal with "contiguous pages", there is not need for nth_page(). Besides that "obvious" folio case, we might end up using nth_page() within CMA allocations (again, could span memory sections), and in one corner case (kfence) when processing memblock allocations (again, could span memory sections). So let's handle all that, add sanity checks, and remove nth_page(). Patch #1 -> #5 : stop making SPARSEMEM_VMEMMAP user-selectable + cleanups Patch #6 -> #13 : disallow folios to have non-contiguous pages Patch #14 -> #20 : remove nth_page() usage within folios Patch #22 : disallow CMA allocations of non-contiguous pages Patch #23 -> #33 : sanity+check + remove nth_page() usage within SG entry Patch #34 : sanity-check + remove nth_page() usage in unpin_user_page_range_dirty_lock() Patch #35 : remove nth_page() in kfence Patch #36 : adjust stale comment regarding nth_page Patch #37 : mm: remove nth_page() A lot of this is inspired from the discussion at [1] between Linus, Jason and me, so cudos to them. This patch (of 37): In an ideal world, we wouldn't have to deal with SPARSEMEM without SPARSEMEM_VMEMMAP, but in particular for 32bit SPARSEMEM_VMEMMAP is considered too costly and consequently not supported. However, if an architecture does support SPARSEMEM with SPARSEMEM_VMEMMAP, let's forbid the user to disable VMEMMAP: just like we already do for arm64, s390 and x86. So if SPARSEMEM_VMEMMAP is supported, don't allow to use SPARSEMEM without SPARSEMEM_VMEMMAP. This implies that the option to not use SPARSEMEM_VMEMMAP will now be gone for loongarch, powerpc, riscv and sparc. All architectures only enable SPARSEMEM_VMEMMAP with 64bit support, so there should not really be a big downside to using the VMEMMAP (quite the contrary). This is a preparation for not supporting (1) folio sizes that exceed a single memory section (2) CMA allocations of non-contiguous page ranges in SPARSEMEM without SPARSEMEM_VMEMMAP configs, whereby we want to limit possible impact as much as possible (e.g., gigantic hugetlb page allocations suddenly fails). Link: https://lkml.kernel.org/r/20250901150359.867252-1-david@redhat.com Link: https://lkml.kernel.org/r/20250901150359.867252-2-david@redhat.com Link: https://lore.kernel.org/all/CAHk-=wiCYfNp4AJLBORU-c7ZyRBUp66W2-Et6cdQ4REx-GyQ_A@mail.gmail.com/T/#u [1] Signed-off-by: David Hildenbrand <david@redhat.com> Acked-by: Zi Yan <ziy@nvidia.com> Acked-by: Mike Rapoport (Microsoft) <rppt@kernel.org> Acked-by: SeongJae Park <sj@kernel.org> Reviewed-by: Wei Yang <richard.weiyang@gmail.com> Reviewed-by: Lorenzo Stoakes <lorenzo.stoakes@oracle.com> Reviewed-by: Liam R. Howlett <Liam.Howlett@oracle.com> Cc: Huacai Chen <chenhuacai@kernel.org> Cc: WANG Xuerui <kernel@xen0n.name> Cc: Madhavan Srinivasan <maddy@linux.ibm.com> Cc: Michael Ellerman <mpe@ellerman.id.au> Cc: Nicholas Piggin <npiggin@gmail.com> Cc: Christophe Leroy <christophe.leroy@csgroup.eu> Cc: Paul Walmsley <paul.walmsley@sifive.com> Cc: Palmer Dabbelt <palmer@dabbelt.com> Cc: Albert Ou <aou@eecs.berkeley.edu> Cc: Alexandre Ghiti <alex@ghiti.fr> Cc: "David S. Miller" <davem@davemloft.net> Cc: Andreas Larsson <andreas@gaisler.com> Cc: Alexander Gordeev <agordeev@linux.ibm.com> Cc: Alexander Potapenko <glider@google.com> Cc: Alexandru Elisei <alexandru.elisei@arm.com> Cc: Alex Dubov <oakad@yahoo.com> Cc: Alex Willamson <alex.williamson@redhat.com> Cc: Bart van Assche <bvanassche@acm.org> Cc: Borislav Betkov <bp@alien8.de> Cc: Brendan Jackman <jackmanb@google.com> Cc: Brett Creeley <brett.creeley@amd.com> Cc: Catalin Marinas <catalin.marinas@arm.com> Cc: Christian Borntraeger <borntraeger@linux.ibm.com> Cc: Christoph Lameter (Ampere) <cl@gentwo.org> Cc: Damien Le Maol <dlemoal@kernel.org> Cc: Dave Airlie <airlied@gmail.com> Cc: Dennis Zhou <dennis@kernel.org> Cc: Dmitriy Vyukov <dvyukov@google.com> Cc: Doug Gilbert <dgilbert@interlog.com> Cc: Heiko Carstens <hca@linux.ibm.com> Cc: Herbert Xu <herbert@gondor.apana.org.au> Cc: Ingo Molnar <mingo@redhat.com> Cc: Inki Dae <m.szyprowski@samsung.com> Cc: James Bottomley <james.bottomley@HansenPartnership.com> Cc: Jani Nikula <jani.nikula@linux.intel.com> Cc: Jason A. Donenfeld <jason@zx2c4.com> Cc: Jason Gunthorpe <jgg@nvidia.com> Cc: Jason Gunthorpe <jgg@ziepe.ca> Cc: Jens Axboe <axboe@kernel.dk> Cc: Jesper Nilsson <jesper.nilsson@axis.com> Cc: Johannes Weiner <hannes@cmpxchg.org> Cc: John Hubbard <jhubbard@nvidia.com> Cc: Jonas Lahtinen <joonas.lahtinen@linux.intel.com> Cc: Kevin Tian <kevin.tian@intel.com> Cc: Lars Persson <lars.persson@axis.com> Cc: Linus Torvalds <torvalds@linux-foundation.org> Cc: Marco Elver <elver@google.com> Cc: "Martin K. Petersen" <martin.petersen@oracle.com> Cc: Maxim Levitky <maximlevitsky@gmail.com> Cc: Michal Hocko <mhocko@suse.com> Cc: Muchun Song <muchun.song@linux.dev> Cc: Niklas Cassel <cassel@kernel.org> Cc: Oscar Salvador <osalvador@suse.de> Cc: Pavel Begunkov <asml.silence@gmail.com> Cc: Peter Xu <peterx@redhat.com> Cc: Robin Murohy <robin.murphy@arm.com> Cc: Rodrigo Vivi <rodrigo.vivi@intel.com> Cc: Shameerali Kolothum Thodi <shameerali.kolothum.thodi@huawei.com> Cc: Shuah Khan <shuah@kernel.org> Cc: Suren Baghdasaryan <surenb@google.com> Cc: Sven Schnelle <svens@linux.ibm.com> Cc: Tejun Heo <tj@kernel.org> Cc: Thomas Bogendoerfer <tsbogend@alpha.franken.de> Cc: Thomas Gleinxer <tglx@linutronix.de> Cc: Tvrtko Ursulin <tursulin@ursulin.net> Cc: Ulf Hansson <ulf.hansson@linaro.org> Cc: Vasily Gorbik <gor@linux.ibm.com> Cc: Vlastimil Babka <vbabka@suse.cz> Cc: Will Deacon <will@kernel.org> Cc: Yishai Hadas <yishaih@nvidia.com> Signed-off-by: Andrew Morton <akpm@linux-foundation.org>
github-actions bot
pushed a commit
that referenced
this pull request
Sep 9, 2025
Patch series "mm: remove nth_page()", v2. As discussed recently with Linus, nth_page() is just nasty and we would like to remove it. To recap, the reason we currently need nth_page() within a folio is because on some kernel configs (SPARSEMEM without SPARSEMEM_VMEMMAP), the memmap is allocated per memory section. While buddy allocations cannot cross memory section boundaries, hugetlb and dax folios can. So crossing a memory section means that "page++" could do the wrong thing. Instead, nth_page() on these problematic configs always goes from page->pfn, to the go from (++pfn)->page, which is rather nasty. Likely, many people have no idea when nth_page() is required and when it might be dropped. We refer to such problematic PFN ranges and "non-contiguous pages". If we only deal with "contiguous pages", there is not need for nth_page(). Besides that "obvious" folio case, we might end up using nth_page() within CMA allocations (again, could span memory sections), and in one corner case (kfence) when processing memblock allocations (again, could span memory sections). So let's handle all that, add sanity checks, and remove nth_page(). Patch #1 -> #5 : stop making SPARSEMEM_VMEMMAP user-selectable + cleanups Patch #6 -> #13 : disallow folios to have non-contiguous pages Patch #14 -> #20 : remove nth_page() usage within folios Patch #22 : disallow CMA allocations of non-contiguous pages Patch #23 -> #33 : sanity+check + remove nth_page() usage within SG entry Patch #34 : sanity-check + remove nth_page() usage in unpin_user_page_range_dirty_lock() Patch #35 : remove nth_page() in kfence Patch #36 : adjust stale comment regarding nth_page Patch #37 : mm: remove nth_page() A lot of this is inspired from the discussion at [1] between Linus, Jason and me, so cudos to them. This patch (of 37): In an ideal world, we wouldn't have to deal with SPARSEMEM without SPARSEMEM_VMEMMAP, but in particular for 32bit SPARSEMEM_VMEMMAP is considered too costly and consequently not supported. However, if an architecture does support SPARSEMEM with SPARSEMEM_VMEMMAP, let's forbid the user to disable VMEMMAP: just like we already do for arm64, s390 and x86. So if SPARSEMEM_VMEMMAP is supported, don't allow to use SPARSEMEM without SPARSEMEM_VMEMMAP. This implies that the option to not use SPARSEMEM_VMEMMAP will now be gone for loongarch, powerpc, riscv and sparc. All architectures only enable SPARSEMEM_VMEMMAP with 64bit support, so there should not really be a big downside to using the VMEMMAP (quite the contrary). This is a preparation for not supporting (1) folio sizes that exceed a single memory section (2) CMA allocations of non-contiguous page ranges in SPARSEMEM without SPARSEMEM_VMEMMAP configs, whereby we want to limit possible impact as much as possible (e.g., gigantic hugetlb page allocations suddenly fails). Link: https://lkml.kernel.org/r/20250901150359.867252-1-david@redhat.com Link: https://lkml.kernel.org/r/20250901150359.867252-2-david@redhat.com Link: https://lore.kernel.org/all/CAHk-=wiCYfNp4AJLBORU-c7ZyRBUp66W2-Et6cdQ4REx-GyQ_A@mail.gmail.com/T/#u [1] Signed-off-by: David Hildenbrand <david@redhat.com> Acked-by: Zi Yan <ziy@nvidia.com> Acked-by: Mike Rapoport (Microsoft) <rppt@kernel.org> Acked-by: SeongJae Park <sj@kernel.org> Reviewed-by: Wei Yang <richard.weiyang@gmail.com> Reviewed-by: Lorenzo Stoakes <lorenzo.stoakes@oracle.com> Reviewed-by: Liam R. Howlett <Liam.Howlett@oracle.com> Cc: Huacai Chen <chenhuacai@kernel.org> Cc: WANG Xuerui <kernel@xen0n.name> Cc: Madhavan Srinivasan <maddy@linux.ibm.com> Cc: Michael Ellerman <mpe@ellerman.id.au> Cc: Nicholas Piggin <npiggin@gmail.com> Cc: Christophe Leroy <christophe.leroy@csgroup.eu> Cc: Paul Walmsley <paul.walmsley@sifive.com> Cc: Palmer Dabbelt <palmer@dabbelt.com> Cc: Albert Ou <aou@eecs.berkeley.edu> Cc: Alexandre Ghiti <alex@ghiti.fr> Cc: "David S. Miller" <davem@davemloft.net> Cc: Andreas Larsson <andreas@gaisler.com> Cc: Alexander Gordeev <agordeev@linux.ibm.com> Cc: Alexander Potapenko <glider@google.com> Cc: Alexandru Elisei <alexandru.elisei@arm.com> Cc: Alex Dubov <oakad@yahoo.com> Cc: Alex Willamson <alex.williamson@redhat.com> Cc: Bart van Assche <bvanassche@acm.org> Cc: Borislav Betkov <bp@alien8.de> Cc: Brendan Jackman <jackmanb@google.com> Cc: Brett Creeley <brett.creeley@amd.com> Cc: Catalin Marinas <catalin.marinas@arm.com> Cc: Christian Borntraeger <borntraeger@linux.ibm.com> Cc: Christoph Lameter (Ampere) <cl@gentwo.org> Cc: Damien Le Maol <dlemoal@kernel.org> Cc: Dave Airlie <airlied@gmail.com> Cc: Dennis Zhou <dennis@kernel.org> Cc: Dmitriy Vyukov <dvyukov@google.com> Cc: Doug Gilbert <dgilbert@interlog.com> Cc: Heiko Carstens <hca@linux.ibm.com> Cc: Herbert Xu <herbert@gondor.apana.org.au> Cc: Ingo Molnar <mingo@redhat.com> Cc: Inki Dae <m.szyprowski@samsung.com> Cc: James Bottomley <james.bottomley@HansenPartnership.com> Cc: Jani Nikula <jani.nikula@linux.intel.com> Cc: Jason A. Donenfeld <jason@zx2c4.com> Cc: Jason Gunthorpe <jgg@nvidia.com> Cc: Jason Gunthorpe <jgg@ziepe.ca> Cc: Jens Axboe <axboe@kernel.dk> Cc: Jesper Nilsson <jesper.nilsson@axis.com> Cc: Johannes Weiner <hannes@cmpxchg.org> Cc: John Hubbard <jhubbard@nvidia.com> Cc: Jonas Lahtinen <joonas.lahtinen@linux.intel.com> Cc: Kevin Tian <kevin.tian@intel.com> Cc: Lars Persson <lars.persson@axis.com> Cc: Linus Torvalds <torvalds@linux-foundation.org> Cc: Marco Elver <elver@google.com> Cc: "Martin K. Petersen" <martin.petersen@oracle.com> Cc: Maxim Levitky <maximlevitsky@gmail.com> Cc: Michal Hocko <mhocko@suse.com> Cc: Muchun Song <muchun.song@linux.dev> Cc: Niklas Cassel <cassel@kernel.org> Cc: Oscar Salvador <osalvador@suse.de> Cc: Pavel Begunkov <asml.silence@gmail.com> Cc: Peter Xu <peterx@redhat.com> Cc: Robin Murohy <robin.murphy@arm.com> Cc: Rodrigo Vivi <rodrigo.vivi@intel.com> Cc: Shameerali Kolothum Thodi <shameerali.kolothum.thodi@huawei.com> Cc: Shuah Khan <shuah@kernel.org> Cc: Suren Baghdasaryan <surenb@google.com> Cc: Sven Schnelle <svens@linux.ibm.com> Cc: Tejun Heo <tj@kernel.org> Cc: Thomas Bogendoerfer <tsbogend@alpha.franken.de> Cc: Thomas Gleinxer <tglx@linutronix.de> Cc: Tvrtko Ursulin <tursulin@ursulin.net> Cc: Ulf Hansson <ulf.hansson@linaro.org> Cc: Vasily Gorbik <gor@linux.ibm.com> Cc: Vlastimil Babka <vbabka@suse.cz> Cc: Will Deacon <will@kernel.org> Cc: Yishai Hadas <yishaih@nvidia.com> Signed-off-by: Andrew Morton <akpm@linux-foundation.org>
github-actions bot
pushed a commit
that referenced
this pull request
Sep 11, 2025
Patch series "mm: remove nth_page()", v2. As discussed recently with Linus, nth_page() is just nasty and we would like to remove it. To recap, the reason we currently need nth_page() within a folio is because on some kernel configs (SPARSEMEM without SPARSEMEM_VMEMMAP), the memmap is allocated per memory section. While buddy allocations cannot cross memory section boundaries, hugetlb and dax folios can. So crossing a memory section means that "page++" could do the wrong thing. Instead, nth_page() on these problematic configs always goes from page->pfn, to the go from (++pfn)->page, which is rather nasty. Likely, many people have no idea when nth_page() is required and when it might be dropped. We refer to such problematic PFN ranges and "non-contiguous pages". If we only deal with "contiguous pages", there is not need for nth_page(). Besides that "obvious" folio case, we might end up using nth_page() within CMA allocations (again, could span memory sections), and in one corner case (kfence) when processing memblock allocations (again, could span memory sections). So let's handle all that, add sanity checks, and remove nth_page(). Patch #1 -> #5 : stop making SPARSEMEM_VMEMMAP user-selectable + cleanups Patch #6 -> #13 : disallow folios to have non-contiguous pages Patch #14 -> #20 : remove nth_page() usage within folios Patch #22 : disallow CMA allocations of non-contiguous pages Patch #23 -> #33 : sanity+check + remove nth_page() usage within SG entry Patch #34 : sanity-check + remove nth_page() usage in unpin_user_page_range_dirty_lock() Patch #35 : remove nth_page() in kfence Patch #36 : adjust stale comment regarding nth_page Patch #37 : mm: remove nth_page() A lot of this is inspired from the discussion at [1] between Linus, Jason and me, so cudos to them. This patch (of 37): In an ideal world, we wouldn't have to deal with SPARSEMEM without SPARSEMEM_VMEMMAP, but in particular for 32bit SPARSEMEM_VMEMMAP is considered too costly and consequently not supported. However, if an architecture does support SPARSEMEM with SPARSEMEM_VMEMMAP, let's forbid the user to disable VMEMMAP: just like we already do for arm64, s390 and x86. So if SPARSEMEM_VMEMMAP is supported, don't allow to use SPARSEMEM without SPARSEMEM_VMEMMAP. This implies that the option to not use SPARSEMEM_VMEMMAP will now be gone for loongarch, powerpc, riscv and sparc. All architectures only enable SPARSEMEM_VMEMMAP with 64bit support, so there should not really be a big downside to using the VMEMMAP (quite the contrary). This is a preparation for not supporting (1) folio sizes that exceed a single memory section (2) CMA allocations of non-contiguous page ranges in SPARSEMEM without SPARSEMEM_VMEMMAP configs, whereby we want to limit possible impact as much as possible (e.g., gigantic hugetlb page allocations suddenly fails). Link: https://lkml.kernel.org/r/20250901150359.867252-1-david@redhat.com Link: https://lkml.kernel.org/r/20250901150359.867252-2-david@redhat.com Link: https://lore.kernel.org/all/CAHk-=wiCYfNp4AJLBORU-c7ZyRBUp66W2-Et6cdQ4REx-GyQ_A@mail.gmail.com/T/#u [1] Signed-off-by: David Hildenbrand <david@redhat.com> Acked-by: Zi Yan <ziy@nvidia.com> Acked-by: Mike Rapoport (Microsoft) <rppt@kernel.org> Acked-by: SeongJae Park <sj@kernel.org> Reviewed-by: Wei Yang <richard.weiyang@gmail.com> Reviewed-by: Lorenzo Stoakes <lorenzo.stoakes@oracle.com> Reviewed-by: Liam R. Howlett <Liam.Howlett@oracle.com> Cc: Huacai Chen <chenhuacai@kernel.org> Cc: WANG Xuerui <kernel@xen0n.name> Cc: Madhavan Srinivasan <maddy@linux.ibm.com> Cc: Michael Ellerman <mpe@ellerman.id.au> Cc: Nicholas Piggin <npiggin@gmail.com> Cc: Christophe Leroy <christophe.leroy@csgroup.eu> Cc: Paul Walmsley <paul.walmsley@sifive.com> Cc: Palmer Dabbelt <palmer@dabbelt.com> Cc: Albert Ou <aou@eecs.berkeley.edu> Cc: Alexandre Ghiti <alex@ghiti.fr> Cc: "David S. Miller" <davem@davemloft.net> Cc: Andreas Larsson <andreas@gaisler.com> Cc: Alexander Gordeev <agordeev@linux.ibm.com> Cc: Alexander Potapenko <glider@google.com> Cc: Alexandru Elisei <alexandru.elisei@arm.com> Cc: Alex Dubov <oakad@yahoo.com> Cc: Alex Willamson <alex.williamson@redhat.com> Cc: Bart van Assche <bvanassche@acm.org> Cc: Borislav Betkov <bp@alien8.de> Cc: Brendan Jackman <jackmanb@google.com> Cc: Brett Creeley <brett.creeley@amd.com> Cc: Catalin Marinas <catalin.marinas@arm.com> Cc: Christian Borntraeger <borntraeger@linux.ibm.com> Cc: Christoph Lameter (Ampere) <cl@gentwo.org> Cc: Damien Le Maol <dlemoal@kernel.org> Cc: Dave Airlie <airlied@gmail.com> Cc: Dennis Zhou <dennis@kernel.org> Cc: Dmitriy Vyukov <dvyukov@google.com> Cc: Doug Gilbert <dgilbert@interlog.com> Cc: Heiko Carstens <hca@linux.ibm.com> Cc: Herbert Xu <herbert@gondor.apana.org.au> Cc: Ingo Molnar <mingo@redhat.com> Cc: Inki Dae <m.szyprowski@samsung.com> Cc: James Bottomley <james.bottomley@HansenPartnership.com> Cc: Jani Nikula <jani.nikula@linux.intel.com> Cc: Jason A. Donenfeld <jason@zx2c4.com> Cc: Jason Gunthorpe <jgg@nvidia.com> Cc: Jason Gunthorpe <jgg@ziepe.ca> Cc: Jens Axboe <axboe@kernel.dk> Cc: Jesper Nilsson <jesper.nilsson@axis.com> Cc: Johannes Weiner <hannes@cmpxchg.org> Cc: John Hubbard <jhubbard@nvidia.com> Cc: Jonas Lahtinen <joonas.lahtinen@linux.intel.com> Cc: Kevin Tian <kevin.tian@intel.com> Cc: Lars Persson <lars.persson@axis.com> Cc: Linus Torvalds <torvalds@linux-foundation.org> Cc: Marco Elver <elver@google.com> Cc: "Martin K. Petersen" <martin.petersen@oracle.com> Cc: Maxim Levitky <maximlevitsky@gmail.com> Cc: Michal Hocko <mhocko@suse.com> Cc: Muchun Song <muchun.song@linux.dev> Cc: Niklas Cassel <cassel@kernel.org> Cc: Oscar Salvador <osalvador@suse.de> Cc: Pavel Begunkov <asml.silence@gmail.com> Cc: Peter Xu <peterx@redhat.com> Cc: Robin Murohy <robin.murphy@arm.com> Cc: Rodrigo Vivi <rodrigo.vivi@intel.com> Cc: Shameerali Kolothum Thodi <shameerali.kolothum.thodi@huawei.com> Cc: Shuah Khan <shuah@kernel.org> Cc: Suren Baghdasaryan <surenb@google.com> Cc: Sven Schnelle <svens@linux.ibm.com> Cc: Tejun Heo <tj@kernel.org> Cc: Thomas Bogendoerfer <tsbogend@alpha.franken.de> Cc: Thomas Gleinxer <tglx@linutronix.de> Cc: Tvrtko Ursulin <tursulin@ursulin.net> Cc: Ulf Hansson <ulf.hansson@linaro.org> Cc: Vasily Gorbik <gor@linux.ibm.com> Cc: Vlastimil Babka <vbabka@suse.cz> Cc: Will Deacon <will@kernel.org> Cc: Yishai Hadas <yishaih@nvidia.com> Signed-off-by: Andrew Morton <akpm@linux-foundation.org>
github-actions bot
pushed a commit
that referenced
this pull request
Sep 12, 2025
Patch series "mm: remove nth_page()", v2. As discussed recently with Linus, nth_page() is just nasty and we would like to remove it. To recap, the reason we currently need nth_page() within a folio is because on some kernel configs (SPARSEMEM without SPARSEMEM_VMEMMAP), the memmap is allocated per memory section. While buddy allocations cannot cross memory section boundaries, hugetlb and dax folios can. So crossing a memory section means that "page++" could do the wrong thing. Instead, nth_page() on these problematic configs always goes from page->pfn, to the go from (++pfn)->page, which is rather nasty. Likely, many people have no idea when nth_page() is required and when it might be dropped. We refer to such problematic PFN ranges and "non-contiguous pages". If we only deal with "contiguous pages", there is not need for nth_page(). Besides that "obvious" folio case, we might end up using nth_page() within CMA allocations (again, could span memory sections), and in one corner case (kfence) when processing memblock allocations (again, could span memory sections). So let's handle all that, add sanity checks, and remove nth_page(). Patch #1 -> #5 : stop making SPARSEMEM_VMEMMAP user-selectable + cleanups Patch #6 -> #13 : disallow folios to have non-contiguous pages Patch #14 -> #20 : remove nth_page() usage within folios Patch #22 : disallow CMA allocations of non-contiguous pages Patch #23 -> #33 : sanity+check + remove nth_page() usage within SG entry Patch #34 : sanity-check + remove nth_page() usage in unpin_user_page_range_dirty_lock() Patch #35 : remove nth_page() in kfence Patch #36 : adjust stale comment regarding nth_page Patch #37 : mm: remove nth_page() A lot of this is inspired from the discussion at [1] between Linus, Jason and me, so cudos to them. This patch (of 37): In an ideal world, we wouldn't have to deal with SPARSEMEM without SPARSEMEM_VMEMMAP, but in particular for 32bit SPARSEMEM_VMEMMAP is considered too costly and consequently not supported. However, if an architecture does support SPARSEMEM with SPARSEMEM_VMEMMAP, let's forbid the user to disable VMEMMAP: just like we already do for arm64, s390 and x86. So if SPARSEMEM_VMEMMAP is supported, don't allow to use SPARSEMEM without SPARSEMEM_VMEMMAP. This implies that the option to not use SPARSEMEM_VMEMMAP will now be gone for loongarch, powerpc, riscv and sparc. All architectures only enable SPARSEMEM_VMEMMAP with 64bit support, so there should not really be a big downside to using the VMEMMAP (quite the contrary). This is a preparation for not supporting (1) folio sizes that exceed a single memory section (2) CMA allocations of non-contiguous page ranges in SPARSEMEM without SPARSEMEM_VMEMMAP configs, whereby we want to limit possible impact as much as possible (e.g., gigantic hugetlb page allocations suddenly fails). Link: https://lkml.kernel.org/r/20250901150359.867252-1-david@redhat.com Link: https://lkml.kernel.org/r/20250901150359.867252-2-david@redhat.com Link: https://lore.kernel.org/all/CAHk-=wiCYfNp4AJLBORU-c7ZyRBUp66W2-Et6cdQ4REx-GyQ_A@mail.gmail.com/T/#u [1] Signed-off-by: David Hildenbrand <david@redhat.com> Acked-by: Zi Yan <ziy@nvidia.com> Acked-by: Mike Rapoport (Microsoft) <rppt@kernel.org> Acked-by: SeongJae Park <sj@kernel.org> Reviewed-by: Wei Yang <richard.weiyang@gmail.com> Reviewed-by: Lorenzo Stoakes <lorenzo.stoakes@oracle.com> Reviewed-by: Liam R. Howlett <Liam.Howlett@oracle.com> Cc: Huacai Chen <chenhuacai@kernel.org> Cc: WANG Xuerui <kernel@xen0n.name> Cc: Madhavan Srinivasan <maddy@linux.ibm.com> Cc: Michael Ellerman <mpe@ellerman.id.au> Cc: Nicholas Piggin <npiggin@gmail.com> Cc: Christophe Leroy <christophe.leroy@csgroup.eu> Cc: Paul Walmsley <paul.walmsley@sifive.com> Cc: Palmer Dabbelt <palmer@dabbelt.com> Cc: Albert Ou <aou@eecs.berkeley.edu> Cc: Alexandre Ghiti <alex@ghiti.fr> Cc: "David S. Miller" <davem@davemloft.net> Cc: Andreas Larsson <andreas@gaisler.com> Cc: Alexander Gordeev <agordeev@linux.ibm.com> Cc: Alexander Potapenko <glider@google.com> Cc: Alexandru Elisei <alexandru.elisei@arm.com> Cc: Alex Dubov <oakad@yahoo.com> Cc: Alex Willamson <alex.williamson@redhat.com> Cc: Bart van Assche <bvanassche@acm.org> Cc: Borislav Betkov <bp@alien8.de> Cc: Brendan Jackman <jackmanb@google.com> Cc: Brett Creeley <brett.creeley@amd.com> Cc: Catalin Marinas <catalin.marinas@arm.com> Cc: Christian Borntraeger <borntraeger@linux.ibm.com> Cc: Christoph Lameter (Ampere) <cl@gentwo.org> Cc: Damien Le Maol <dlemoal@kernel.org> Cc: Dave Airlie <airlied@gmail.com> Cc: Dennis Zhou <dennis@kernel.org> Cc: Dmitriy Vyukov <dvyukov@google.com> Cc: Doug Gilbert <dgilbert@interlog.com> Cc: Heiko Carstens <hca@linux.ibm.com> Cc: Herbert Xu <herbert@gondor.apana.org.au> Cc: Ingo Molnar <mingo@redhat.com> Cc: Inki Dae <m.szyprowski@samsung.com> Cc: James Bottomley <james.bottomley@HansenPartnership.com> Cc: Jani Nikula <jani.nikula@linux.intel.com> Cc: Jason A. Donenfeld <jason@zx2c4.com> Cc: Jason Gunthorpe <jgg@nvidia.com> Cc: Jason Gunthorpe <jgg@ziepe.ca> Cc: Jens Axboe <axboe@kernel.dk> Cc: Jesper Nilsson <jesper.nilsson@axis.com> Cc: Johannes Weiner <hannes@cmpxchg.org> Cc: John Hubbard <jhubbard@nvidia.com> Cc: Jonas Lahtinen <joonas.lahtinen@linux.intel.com> Cc: Kevin Tian <kevin.tian@intel.com> Cc: Lars Persson <lars.persson@axis.com> Cc: Linus Torvalds <torvalds@linux-foundation.org> Cc: Marco Elver <elver@google.com> Cc: "Martin K. Petersen" <martin.petersen@oracle.com> Cc: Maxim Levitky <maximlevitsky@gmail.com> Cc: Michal Hocko <mhocko@suse.com> Cc: Muchun Song <muchun.song@linux.dev> Cc: Niklas Cassel <cassel@kernel.org> Cc: Oscar Salvador <osalvador@suse.de> Cc: Pavel Begunkov <asml.silence@gmail.com> Cc: Peter Xu <peterx@redhat.com> Cc: Robin Murohy <robin.murphy@arm.com> Cc: Rodrigo Vivi <rodrigo.vivi@intel.com> Cc: Shameerali Kolothum Thodi <shameerali.kolothum.thodi@huawei.com> Cc: Shuah Khan <shuah@kernel.org> Cc: Suren Baghdasaryan <surenb@google.com> Cc: Sven Schnelle <svens@linux.ibm.com> Cc: Tejun Heo <tj@kernel.org> Cc: Thomas Bogendoerfer <tsbogend@alpha.franken.de> Cc: Thomas Gleinxer <tglx@linutronix.de> Cc: Tvrtko Ursulin <tursulin@ursulin.net> Cc: Ulf Hansson <ulf.hansson@linaro.org> Cc: Vasily Gorbik <gor@linux.ibm.com> Cc: Vlastimil Babka <vbabka@suse.cz> Cc: Will Deacon <will@kernel.org> Cc: Yishai Hadas <yishaih@nvidia.com> Signed-off-by: Andrew Morton <akpm@linux-foundation.org>
github-actions bot
pushed a commit
that referenced
this pull request
Sep 13, 2025
Patch series "mm: remove nth_page()", v2. As discussed recently with Linus, nth_page() is just nasty and we would like to remove it. To recap, the reason we currently need nth_page() within a folio is because on some kernel configs (SPARSEMEM without SPARSEMEM_VMEMMAP), the memmap is allocated per memory section. While buddy allocations cannot cross memory section boundaries, hugetlb and dax folios can. So crossing a memory section means that "page++" could do the wrong thing. Instead, nth_page() on these problematic configs always goes from page->pfn, to the go from (++pfn)->page, which is rather nasty. Likely, many people have no idea when nth_page() is required and when it might be dropped. We refer to such problematic PFN ranges and "non-contiguous pages". If we only deal with "contiguous pages", there is not need for nth_page(). Besides that "obvious" folio case, we might end up using nth_page() within CMA allocations (again, could span memory sections), and in one corner case (kfence) when processing memblock allocations (again, could span memory sections). So let's handle all that, add sanity checks, and remove nth_page(). Patch #1 -> #5 : stop making SPARSEMEM_VMEMMAP user-selectable + cleanups Patch #6 -> #13 : disallow folios to have non-contiguous pages Patch #14 -> #20 : remove nth_page() usage within folios Patch #22 : disallow CMA allocations of non-contiguous pages Patch #23 -> #33 : sanity+check + remove nth_page() usage within SG entry Patch #34 : sanity-check + remove nth_page() usage in unpin_user_page_range_dirty_lock() Patch #35 : remove nth_page() in kfence Patch #36 : adjust stale comment regarding nth_page Patch #37 : mm: remove nth_page() A lot of this is inspired from the discussion at [1] between Linus, Jason and me, so cudos to them. This patch (of 37): In an ideal world, we wouldn't have to deal with SPARSEMEM without SPARSEMEM_VMEMMAP, but in particular for 32bit SPARSEMEM_VMEMMAP is considered too costly and consequently not supported. However, if an architecture does support SPARSEMEM with SPARSEMEM_VMEMMAP, let's forbid the user to disable VMEMMAP: just like we already do for arm64, s390 and x86. So if SPARSEMEM_VMEMMAP is supported, don't allow to use SPARSEMEM without SPARSEMEM_VMEMMAP. This implies that the option to not use SPARSEMEM_VMEMMAP will now be gone for loongarch, powerpc, riscv and sparc. All architectures only enable SPARSEMEM_VMEMMAP with 64bit support, so there should not really be a big downside to using the VMEMMAP (quite the contrary). This is a preparation for not supporting (1) folio sizes that exceed a single memory section (2) CMA allocations of non-contiguous page ranges in SPARSEMEM without SPARSEMEM_VMEMMAP configs, whereby we want to limit possible impact as much as possible (e.g., gigantic hugetlb page allocations suddenly fails). Link: https://lkml.kernel.org/r/20250901150359.867252-1-david@redhat.com Link: https://lkml.kernel.org/r/20250901150359.867252-2-david@redhat.com Link: https://lore.kernel.org/all/CAHk-=wiCYfNp4AJLBORU-c7ZyRBUp66W2-Et6cdQ4REx-GyQ_A@mail.gmail.com/T/#u [1] Signed-off-by: David Hildenbrand <david@redhat.com> Acked-by: Zi Yan <ziy@nvidia.com> Acked-by: Mike Rapoport (Microsoft) <rppt@kernel.org> Acked-by: SeongJae Park <sj@kernel.org> Reviewed-by: Wei Yang <richard.weiyang@gmail.com> Reviewed-by: Lorenzo Stoakes <lorenzo.stoakes@oracle.com> Reviewed-by: Liam R. Howlett <Liam.Howlett@oracle.com> Cc: Huacai Chen <chenhuacai@kernel.org> Cc: WANG Xuerui <kernel@xen0n.name> Cc: Madhavan Srinivasan <maddy@linux.ibm.com> Cc: Michael Ellerman <mpe@ellerman.id.au> Cc: Nicholas Piggin <npiggin@gmail.com> Cc: Christophe Leroy <christophe.leroy@csgroup.eu> Cc: Paul Walmsley <paul.walmsley@sifive.com> Cc: Palmer Dabbelt <palmer@dabbelt.com> Cc: Albert Ou <aou@eecs.berkeley.edu> Cc: Alexandre Ghiti <alex@ghiti.fr> Cc: "David S. Miller" <davem@davemloft.net> Cc: Andreas Larsson <andreas@gaisler.com> Cc: Alexander Gordeev <agordeev@linux.ibm.com> Cc: Alexander Potapenko <glider@google.com> Cc: Alexandru Elisei <alexandru.elisei@arm.com> Cc: Alex Dubov <oakad@yahoo.com> Cc: Alex Willamson <alex.williamson@redhat.com> Cc: Bart van Assche <bvanassche@acm.org> Cc: Borislav Betkov <bp@alien8.de> Cc: Brendan Jackman <jackmanb@google.com> Cc: Brett Creeley <brett.creeley@amd.com> Cc: Catalin Marinas <catalin.marinas@arm.com> Cc: Christian Borntraeger <borntraeger@linux.ibm.com> Cc: Christoph Lameter (Ampere) <cl@gentwo.org> Cc: Damien Le Maol <dlemoal@kernel.org> Cc: Dave Airlie <airlied@gmail.com> Cc: Dennis Zhou <dennis@kernel.org> Cc: Dmitriy Vyukov <dvyukov@google.com> Cc: Doug Gilbert <dgilbert@interlog.com> Cc: Heiko Carstens <hca@linux.ibm.com> Cc: Herbert Xu <herbert@gondor.apana.org.au> Cc: Ingo Molnar <mingo@redhat.com> Cc: Inki Dae <m.szyprowski@samsung.com> Cc: James Bottomley <james.bottomley@HansenPartnership.com> Cc: Jani Nikula <jani.nikula@linux.intel.com> Cc: Jason A. Donenfeld <jason@zx2c4.com> Cc: Jason Gunthorpe <jgg@nvidia.com> Cc: Jason Gunthorpe <jgg@ziepe.ca> Cc: Jens Axboe <axboe@kernel.dk> Cc: Jesper Nilsson <jesper.nilsson@axis.com> Cc: Johannes Weiner <hannes@cmpxchg.org> Cc: John Hubbard <jhubbard@nvidia.com> Cc: Jonas Lahtinen <joonas.lahtinen@linux.intel.com> Cc: Kevin Tian <kevin.tian@intel.com> Cc: Lars Persson <lars.persson@axis.com> Cc: Linus Torvalds <torvalds@linux-foundation.org> Cc: Marco Elver <elver@google.com> Cc: "Martin K. Petersen" <martin.petersen@oracle.com> Cc: Maxim Levitky <maximlevitsky@gmail.com> Cc: Michal Hocko <mhocko@suse.com> Cc: Muchun Song <muchun.song@linux.dev> Cc: Niklas Cassel <cassel@kernel.org> Cc: Oscar Salvador <osalvador@suse.de> Cc: Pavel Begunkov <asml.silence@gmail.com> Cc: Peter Xu <peterx@redhat.com> Cc: Robin Murohy <robin.murphy@arm.com> Cc: Rodrigo Vivi <rodrigo.vivi@intel.com> Cc: Shameerali Kolothum Thodi <shameerali.kolothum.thodi@huawei.com> Cc: Shuah Khan <shuah@kernel.org> Cc: Suren Baghdasaryan <surenb@google.com> Cc: Sven Schnelle <svens@linux.ibm.com> Cc: Tejun Heo <tj@kernel.org> Cc: Thomas Bogendoerfer <tsbogend@alpha.franken.de> Cc: Thomas Gleinxer <tglx@linutronix.de> Cc: Tvrtko Ursulin <tursulin@ursulin.net> Cc: Ulf Hansson <ulf.hansson@linaro.org> Cc: Vasily Gorbik <gor@linux.ibm.com> Cc: Vlastimil Babka <vbabka@suse.cz> Cc: Will Deacon <will@kernel.org> Cc: Yishai Hadas <yishaih@nvidia.com> Signed-off-by: Andrew Morton <akpm@linux-foundation.org>
github-actions bot
pushed a commit
that referenced
this pull request
Sep 16, 2025
Patch series "mm: remove nth_page()", v2. As discussed recently with Linus, nth_page() is just nasty and we would like to remove it. To recap, the reason we currently need nth_page() within a folio is because on some kernel configs (SPARSEMEM without SPARSEMEM_VMEMMAP), the memmap is allocated per memory section. While buddy allocations cannot cross memory section boundaries, hugetlb and dax folios can. So crossing a memory section means that "page++" could do the wrong thing. Instead, nth_page() on these problematic configs always goes from page->pfn, to the go from (++pfn)->page, which is rather nasty. Likely, many people have no idea when nth_page() is required and when it might be dropped. We refer to such problematic PFN ranges and "non-contiguous pages". If we only deal with "contiguous pages", there is not need for nth_page(). Besides that "obvious" folio case, we might end up using nth_page() within CMA allocations (again, could span memory sections), and in one corner case (kfence) when processing memblock allocations (again, could span memory sections). So let's handle all that, add sanity checks, and remove nth_page(). Patch #1 -> #5 : stop making SPARSEMEM_VMEMMAP user-selectable + cleanups Patch #6 -> #13 : disallow folios to have non-contiguous pages Patch #14 -> #20 : remove nth_page() usage within folios Patch #22 : disallow CMA allocations of non-contiguous pages Patch #23 -> #33 : sanity+check + remove nth_page() usage within SG entry Patch #34 : sanity-check + remove nth_page() usage in unpin_user_page_range_dirty_lock() Patch #35 : remove nth_page() in kfence Patch #36 : adjust stale comment regarding nth_page Patch #37 : mm: remove nth_page() A lot of this is inspired from the discussion at [1] between Linus, Jason and me, so cudos to them. This patch (of 37): In an ideal world, we wouldn't have to deal with SPARSEMEM without SPARSEMEM_VMEMMAP, but in particular for 32bit SPARSEMEM_VMEMMAP is considered too costly and consequently not supported. However, if an architecture does support SPARSEMEM with SPARSEMEM_VMEMMAP, let's forbid the user to disable VMEMMAP: just like we already do for arm64, s390 and x86. So if SPARSEMEM_VMEMMAP is supported, don't allow to use SPARSEMEM without SPARSEMEM_VMEMMAP. This implies that the option to not use SPARSEMEM_VMEMMAP will now be gone for loongarch, powerpc, riscv and sparc. All architectures only enable SPARSEMEM_VMEMMAP with 64bit support, so there should not really be a big downside to using the VMEMMAP (quite the contrary). This is a preparation for not supporting (1) folio sizes that exceed a single memory section (2) CMA allocations of non-contiguous page ranges in SPARSEMEM without SPARSEMEM_VMEMMAP configs, whereby we want to limit possible impact as much as possible (e.g., gigantic hugetlb page allocations suddenly fails). Link: https://lkml.kernel.org/r/20250901150359.867252-1-david@redhat.com Link: https://lkml.kernel.org/r/20250901150359.867252-2-david@redhat.com Link: https://lore.kernel.org/all/CAHk-=wiCYfNp4AJLBORU-c7ZyRBUp66W2-Et6cdQ4REx-GyQ_A@mail.gmail.com/T/#u [1] Signed-off-by: David Hildenbrand <david@redhat.com> Acked-by: Zi Yan <ziy@nvidia.com> Acked-by: Mike Rapoport (Microsoft) <rppt@kernel.org> Acked-by: SeongJae Park <sj@kernel.org> Reviewed-by: Wei Yang <richard.weiyang@gmail.com> Reviewed-by: Lorenzo Stoakes <lorenzo.stoakes@oracle.com> Reviewed-by: Liam R. Howlett <Liam.Howlett@oracle.com> Cc: Huacai Chen <chenhuacai@kernel.org> Cc: WANG Xuerui <kernel@xen0n.name> Cc: Madhavan Srinivasan <maddy@linux.ibm.com> Cc: Michael Ellerman <mpe@ellerman.id.au> Cc: Nicholas Piggin <npiggin@gmail.com> Cc: Christophe Leroy <christophe.leroy@csgroup.eu> Cc: Paul Walmsley <paul.walmsley@sifive.com> Cc: Palmer Dabbelt <palmer@dabbelt.com> Cc: Albert Ou <aou@eecs.berkeley.edu> Cc: Alexandre Ghiti <alex@ghiti.fr> Cc: "David S. Miller" <davem@davemloft.net> Cc: Andreas Larsson <andreas@gaisler.com> Cc: Alexander Gordeev <agordeev@linux.ibm.com> Cc: Alexander Potapenko <glider@google.com> Cc: Alexandru Elisei <alexandru.elisei@arm.com> Cc: Alex Dubov <oakad@yahoo.com> Cc: Alex Willamson <alex.williamson@redhat.com> Cc: Bart van Assche <bvanassche@acm.org> Cc: Borislav Betkov <bp@alien8.de> Cc: Brendan Jackman <jackmanb@google.com> Cc: Brett Creeley <brett.creeley@amd.com> Cc: Catalin Marinas <catalin.marinas@arm.com> Cc: Christian Borntraeger <borntraeger@linux.ibm.com> Cc: Christoph Lameter (Ampere) <cl@gentwo.org> Cc: Damien Le Maol <dlemoal@kernel.org> Cc: Dave Airlie <airlied@gmail.com> Cc: Dennis Zhou <dennis@kernel.org> Cc: Dmitriy Vyukov <dvyukov@google.com> Cc: Doug Gilbert <dgilbert@interlog.com> Cc: Heiko Carstens <hca@linux.ibm.com> Cc: Herbert Xu <herbert@gondor.apana.org.au> Cc: Ingo Molnar <mingo@redhat.com> Cc: Inki Dae <m.szyprowski@samsung.com> Cc: James Bottomley <james.bottomley@HansenPartnership.com> Cc: Jani Nikula <jani.nikula@linux.intel.com> Cc: Jason A. Donenfeld <jason@zx2c4.com> Cc: Jason Gunthorpe <jgg@nvidia.com> Cc: Jason Gunthorpe <jgg@ziepe.ca> Cc: Jens Axboe <axboe@kernel.dk> Cc: Jesper Nilsson <jesper.nilsson@axis.com> Cc: Johannes Weiner <hannes@cmpxchg.org> Cc: John Hubbard <jhubbard@nvidia.com> Cc: Jonas Lahtinen <joonas.lahtinen@linux.intel.com> Cc: Kevin Tian <kevin.tian@intel.com> Cc: Lars Persson <lars.persson@axis.com> Cc: Linus Torvalds <torvalds@linux-foundation.org> Cc: Marco Elver <elver@google.com> Cc: "Martin K. Petersen" <martin.petersen@oracle.com> Cc: Maxim Levitky <maximlevitsky@gmail.com> Cc: Michal Hocko <mhocko@suse.com> Cc: Muchun Song <muchun.song@linux.dev> Cc: Niklas Cassel <cassel@kernel.org> Cc: Oscar Salvador <osalvador@suse.de> Cc: Pavel Begunkov <asml.silence@gmail.com> Cc: Peter Xu <peterx@redhat.com> Cc: Robin Murohy <robin.murphy@arm.com> Cc: Rodrigo Vivi <rodrigo.vivi@intel.com> Cc: Shameerali Kolothum Thodi <shameerali.kolothum.thodi@huawei.com> Cc: Shuah Khan <shuah@kernel.org> Cc: Suren Baghdasaryan <surenb@google.com> Cc: Sven Schnelle <svens@linux.ibm.com> Cc: Tejun Heo <tj@kernel.org> Cc: Thomas Bogendoerfer <tsbogend@alpha.franken.de> Cc: Thomas Gleinxer <tglx@linutronix.de> Cc: Tvrtko Ursulin <tursulin@ursulin.net> Cc: Ulf Hansson <ulf.hansson@linaro.org> Cc: Vasily Gorbik <gor@linux.ibm.com> Cc: Vlastimil Babka <vbabka@suse.cz> Cc: Will Deacon <will@kernel.org> Cc: Yishai Hadas <yishaih@nvidia.com> Signed-off-by: Andrew Morton <akpm@linux-foundation.org>
github-actions bot
pushed a commit
that referenced
this pull request
Sep 17, 2025
Patch series "mm: remove nth_page()", v2. As discussed recently with Linus, nth_page() is just nasty and we would like to remove it. To recap, the reason we currently need nth_page() within a folio is because on some kernel configs (SPARSEMEM without SPARSEMEM_VMEMMAP), the memmap is allocated per memory section. While buddy allocations cannot cross memory section boundaries, hugetlb and dax folios can. So crossing a memory section means that "page++" could do the wrong thing. Instead, nth_page() on these problematic configs always goes from page->pfn, to the go from (++pfn)->page, which is rather nasty. Likely, many people have no idea when nth_page() is required and when it might be dropped. We refer to such problematic PFN ranges and "non-contiguous pages". If we only deal with "contiguous pages", there is not need for nth_page(). Besides that "obvious" folio case, we might end up using nth_page() within CMA allocations (again, could span memory sections), and in one corner case (kfence) when processing memblock allocations (again, could span memory sections). So let's handle all that, add sanity checks, and remove nth_page(). Patch #1 -> #5 : stop making SPARSEMEM_VMEMMAP user-selectable + cleanups Patch #6 -> #13 : disallow folios to have non-contiguous pages Patch #14 -> #20 : remove nth_page() usage within folios Patch #22 : disallow CMA allocations of non-contiguous pages Patch #23 -> #33 : sanity+check + remove nth_page() usage within SG entry Patch #34 : sanity-check + remove nth_page() usage in unpin_user_page_range_dirty_lock() Patch #35 : remove nth_page() in kfence Patch #36 : adjust stale comment regarding nth_page Patch #37 : mm: remove nth_page() A lot of this is inspired from the discussion at [1] between Linus, Jason and me, so cudos to them. This patch (of 37): In an ideal world, we wouldn't have to deal with SPARSEMEM without SPARSEMEM_VMEMMAP, but in particular for 32bit SPARSEMEM_VMEMMAP is considered too costly and consequently not supported. However, if an architecture does support SPARSEMEM with SPARSEMEM_VMEMMAP, let's forbid the user to disable VMEMMAP: just like we already do for arm64, s390 and x86. So if SPARSEMEM_VMEMMAP is supported, don't allow to use SPARSEMEM without SPARSEMEM_VMEMMAP. This implies that the option to not use SPARSEMEM_VMEMMAP will now be gone for loongarch, powerpc, riscv and sparc. All architectures only enable SPARSEMEM_VMEMMAP with 64bit support, so there should not really be a big downside to using the VMEMMAP (quite the contrary). This is a preparation for not supporting (1) folio sizes that exceed a single memory section (2) CMA allocations of non-contiguous page ranges in SPARSEMEM without SPARSEMEM_VMEMMAP configs, whereby we want to limit possible impact as much as possible (e.g., gigantic hugetlb page allocations suddenly fails). Link: https://lkml.kernel.org/r/20250901150359.867252-1-david@redhat.com Link: https://lkml.kernel.org/r/20250901150359.867252-2-david@redhat.com Link: https://lore.kernel.org/all/CAHk-=wiCYfNp4AJLBORU-c7ZyRBUp66W2-Et6cdQ4REx-GyQ_A@mail.gmail.com/T/#u [1] Signed-off-by: David Hildenbrand <david@redhat.com> Acked-by: Zi Yan <ziy@nvidia.com> Acked-by: Mike Rapoport (Microsoft) <rppt@kernel.org> Acked-by: SeongJae Park <sj@kernel.org> Reviewed-by: Wei Yang <richard.weiyang@gmail.com> Reviewed-by: Lorenzo Stoakes <lorenzo.stoakes@oracle.com> Reviewed-by: Liam R. Howlett <Liam.Howlett@oracle.com> Cc: Huacai Chen <chenhuacai@kernel.org> Cc: WANG Xuerui <kernel@xen0n.name> Cc: Madhavan Srinivasan <maddy@linux.ibm.com> Cc: Michael Ellerman <mpe@ellerman.id.au> Cc: Nicholas Piggin <npiggin@gmail.com> Cc: Christophe Leroy <christophe.leroy@csgroup.eu> Cc: Paul Walmsley <paul.walmsley@sifive.com> Cc: Palmer Dabbelt <palmer@dabbelt.com> Cc: Albert Ou <aou@eecs.berkeley.edu> Cc: Alexandre Ghiti <alex@ghiti.fr> Cc: "David S. Miller" <davem@davemloft.net> Cc: Andreas Larsson <andreas@gaisler.com> Cc: Alexander Gordeev <agordeev@linux.ibm.com> Cc: Alexander Potapenko <glider@google.com> Cc: Alexandru Elisei <alexandru.elisei@arm.com> Cc: Alex Dubov <oakad@yahoo.com> Cc: Alex Willamson <alex.williamson@redhat.com> Cc: Bart van Assche <bvanassche@acm.org> Cc: Borislav Betkov <bp@alien8.de> Cc: Brendan Jackman <jackmanb@google.com> Cc: Brett Creeley <brett.creeley@amd.com> Cc: Catalin Marinas <catalin.marinas@arm.com> Cc: Christian Borntraeger <borntraeger@linux.ibm.com> Cc: Christoph Lameter (Ampere) <cl@gentwo.org> Cc: Damien Le Maol <dlemoal@kernel.org> Cc: Dave Airlie <airlied@gmail.com> Cc: Dennis Zhou <dennis@kernel.org> Cc: Dmitriy Vyukov <dvyukov@google.com> Cc: Doug Gilbert <dgilbert@interlog.com> Cc: Heiko Carstens <hca@linux.ibm.com> Cc: Herbert Xu <herbert@gondor.apana.org.au> Cc: Ingo Molnar <mingo@redhat.com> Cc: Inki Dae <m.szyprowski@samsung.com> Cc: James Bottomley <james.bottomley@HansenPartnership.com> Cc: Jani Nikula <jani.nikula@linux.intel.com> Cc: Jason A. Donenfeld <jason@zx2c4.com> Cc: Jason Gunthorpe <jgg@nvidia.com> Cc: Jason Gunthorpe <jgg@ziepe.ca> Cc: Jens Axboe <axboe@kernel.dk> Cc: Jesper Nilsson <jesper.nilsson@axis.com> Cc: Johannes Weiner <hannes@cmpxchg.org> Cc: John Hubbard <jhubbard@nvidia.com> Cc: Jonas Lahtinen <joonas.lahtinen@linux.intel.com> Cc: Kevin Tian <kevin.tian@intel.com> Cc: Lars Persson <lars.persson@axis.com> Cc: Linus Torvalds <torvalds@linux-foundation.org> Cc: Marco Elver <elver@google.com> Cc: "Martin K. Petersen" <martin.petersen@oracle.com> Cc: Maxim Levitky <maximlevitsky@gmail.com> Cc: Michal Hocko <mhocko@suse.com> Cc: Muchun Song <muchun.song@linux.dev> Cc: Niklas Cassel <cassel@kernel.org> Cc: Oscar Salvador <osalvador@suse.de> Cc: Pavel Begunkov <asml.silence@gmail.com> Cc: Peter Xu <peterx@redhat.com> Cc: Robin Murohy <robin.murphy@arm.com> Cc: Rodrigo Vivi <rodrigo.vivi@intel.com> Cc: Shameerali Kolothum Thodi <shameerali.kolothum.thodi@huawei.com> Cc: Shuah Khan <shuah@kernel.org> Cc: Suren Baghdasaryan <surenb@google.com> Cc: Sven Schnelle <svens@linux.ibm.com> Cc: Tejun Heo <tj@kernel.org> Cc: Thomas Bogendoerfer <tsbogend@alpha.franken.de> Cc: Thomas Gleinxer <tglx@linutronix.de> Cc: Tvrtko Ursulin <tursulin@ursulin.net> Cc: Ulf Hansson <ulf.hansson@linaro.org> Cc: Vasily Gorbik <gor@linux.ibm.com> Cc: Vlastimil Babka <vbabka@suse.cz> Cc: Will Deacon <will@kernel.org> Cc: Yishai Hadas <yishaih@nvidia.com> Signed-off-by: Andrew Morton <akpm@linux-foundation.org>
github-actions bot
pushed a commit
that referenced
this pull request
Sep 18, 2025
Patch series "mm: remove nth_page()", v2. As discussed recently with Linus, nth_page() is just nasty and we would like to remove it. To recap, the reason we currently need nth_page() within a folio is because on some kernel configs (SPARSEMEM without SPARSEMEM_VMEMMAP), the memmap is allocated per memory section. While buddy allocations cannot cross memory section boundaries, hugetlb and dax folios can. So crossing a memory section means that "page++" could do the wrong thing. Instead, nth_page() on these problematic configs always goes from page->pfn, to the go from (++pfn)->page, which is rather nasty. Likely, many people have no idea when nth_page() is required and when it might be dropped. We refer to such problematic PFN ranges and "non-contiguous pages". If we only deal with "contiguous pages", there is not need for nth_page(). Besides that "obvious" folio case, we might end up using nth_page() within CMA allocations (again, could span memory sections), and in one corner case (kfence) when processing memblock allocations (again, could span memory sections). So let's handle all that, add sanity checks, and remove nth_page(). Patch #1 -> #5 : stop making SPARSEMEM_VMEMMAP user-selectable + cleanups Patch #6 -> #13 : disallow folios to have non-contiguous pages Patch #14 -> #20 : remove nth_page() usage within folios Patch #22 : disallow CMA allocations of non-contiguous pages Patch #23 -> #33 : sanity+check + remove nth_page() usage within SG entry Patch #34 : sanity-check + remove nth_page() usage in unpin_user_page_range_dirty_lock() Patch #35 : remove nth_page() in kfence Patch #36 : adjust stale comment regarding nth_page Patch #37 : mm: remove nth_page() A lot of this is inspired from the discussion at [1] between Linus, Jason and me, so cudos to them. This patch (of 37): In an ideal world, we wouldn't have to deal with SPARSEMEM without SPARSEMEM_VMEMMAP, but in particular for 32bit SPARSEMEM_VMEMMAP is considered too costly and consequently not supported. However, if an architecture does support SPARSEMEM with SPARSEMEM_VMEMMAP, let's forbid the user to disable VMEMMAP: just like we already do for arm64, s390 and x86. So if SPARSEMEM_VMEMMAP is supported, don't allow to use SPARSEMEM without SPARSEMEM_VMEMMAP. This implies that the option to not use SPARSEMEM_VMEMMAP will now be gone for loongarch, powerpc, riscv and sparc. All architectures only enable SPARSEMEM_VMEMMAP with 64bit support, so there should not really be a big downside to using the VMEMMAP (quite the contrary). This is a preparation for not supporting (1) folio sizes that exceed a single memory section (2) CMA allocations of non-contiguous page ranges in SPARSEMEM without SPARSEMEM_VMEMMAP configs, whereby we want to limit possible impact as much as possible (e.g., gigantic hugetlb page allocations suddenly fails). Link: https://lkml.kernel.org/r/20250901150359.867252-1-david@redhat.com Link: https://lkml.kernel.org/r/20250901150359.867252-2-david@redhat.com Link: https://lore.kernel.org/all/CAHk-=wiCYfNp4AJLBORU-c7ZyRBUp66W2-Et6cdQ4REx-GyQ_A@mail.gmail.com/T/#u [1] Signed-off-by: David Hildenbrand <david@redhat.com> Acked-by: Zi Yan <ziy@nvidia.com> Acked-by: Mike Rapoport (Microsoft) <rppt@kernel.org> Acked-by: SeongJae Park <sj@kernel.org> Reviewed-by: Wei Yang <richard.weiyang@gmail.com> Reviewed-by: Lorenzo Stoakes <lorenzo.stoakes@oracle.com> Reviewed-by: Liam R. Howlett <Liam.Howlett@oracle.com> Cc: Huacai Chen <chenhuacai@kernel.org> Cc: WANG Xuerui <kernel@xen0n.name> Cc: Madhavan Srinivasan <maddy@linux.ibm.com> Cc: Michael Ellerman <mpe@ellerman.id.au> Cc: Nicholas Piggin <npiggin@gmail.com> Cc: Christophe Leroy <christophe.leroy@csgroup.eu> Cc: Paul Walmsley <paul.walmsley@sifive.com> Cc: Palmer Dabbelt <palmer@dabbelt.com> Cc: Albert Ou <aou@eecs.berkeley.edu> Cc: Alexandre Ghiti <alex@ghiti.fr> Cc: "David S. Miller" <davem@davemloft.net> Cc: Andreas Larsson <andreas@gaisler.com> Cc: Alexander Gordeev <agordeev@linux.ibm.com> Cc: Alexander Potapenko <glider@google.com> Cc: Alexandru Elisei <alexandru.elisei@arm.com> Cc: Alex Dubov <oakad@yahoo.com> Cc: Alex Willamson <alex.williamson@redhat.com> Cc: Bart van Assche <bvanassche@acm.org> Cc: Borislav Betkov <bp@alien8.de> Cc: Brendan Jackman <jackmanb@google.com> Cc: Brett Creeley <brett.creeley@amd.com> Cc: Catalin Marinas <catalin.marinas@arm.com> Cc: Christian Borntraeger <borntraeger@linux.ibm.com> Cc: Christoph Lameter (Ampere) <cl@gentwo.org> Cc: Damien Le Maol <dlemoal@kernel.org> Cc: Dave Airlie <airlied@gmail.com> Cc: Dennis Zhou <dennis@kernel.org> Cc: Dmitriy Vyukov <dvyukov@google.com> Cc: Doug Gilbert <dgilbert@interlog.com> Cc: Heiko Carstens <hca@linux.ibm.com> Cc: Herbert Xu <herbert@gondor.apana.org.au> Cc: Ingo Molnar <mingo@redhat.com> Cc: Inki Dae <m.szyprowski@samsung.com> Cc: James Bottomley <james.bottomley@HansenPartnership.com> Cc: Jani Nikula <jani.nikula@linux.intel.com> Cc: Jason A. Donenfeld <jason@zx2c4.com> Cc: Jason Gunthorpe <jgg@nvidia.com> Cc: Jason Gunthorpe <jgg@ziepe.ca> Cc: Jens Axboe <axboe@kernel.dk> Cc: Jesper Nilsson <jesper.nilsson@axis.com> Cc: Johannes Weiner <hannes@cmpxchg.org> Cc: John Hubbard <jhubbard@nvidia.com> Cc: Jonas Lahtinen <joonas.lahtinen@linux.intel.com> Cc: Kevin Tian <kevin.tian@intel.com> Cc: Lars Persson <lars.persson@axis.com> Cc: Linus Torvalds <torvalds@linux-foundation.org> Cc: Marco Elver <elver@google.com> Cc: "Martin K. Petersen" <martin.petersen@oracle.com> Cc: Maxim Levitky <maximlevitsky@gmail.com> Cc: Michal Hocko <mhocko@suse.com> Cc: Muchun Song <muchun.song@linux.dev> Cc: Niklas Cassel <cassel@kernel.org> Cc: Oscar Salvador <osalvador@suse.de> Cc: Pavel Begunkov <asml.silence@gmail.com> Cc: Peter Xu <peterx@redhat.com> Cc: Robin Murohy <robin.murphy@arm.com> Cc: Rodrigo Vivi <rodrigo.vivi@intel.com> Cc: Shameerali Kolothum Thodi <shameerali.kolothum.thodi@huawei.com> Cc: Shuah Khan <shuah@kernel.org> Cc: Suren Baghdasaryan <surenb@google.com> Cc: Sven Schnelle <svens@linux.ibm.com> Cc: Tejun Heo <tj@kernel.org> Cc: Thomas Bogendoerfer <tsbogend@alpha.franken.de> Cc: Thomas Gleinxer <tglx@linutronix.de> Cc: Tvrtko Ursulin <tursulin@ursulin.net> Cc: Ulf Hansson <ulf.hansson@linaro.org> Cc: Vasily Gorbik <gor@linux.ibm.com> Cc: Vlastimil Babka <vbabka@suse.cz> Cc: Will Deacon <will@kernel.org> Cc: Yishai Hadas <yishaih@nvidia.com> Signed-off-by: Andrew Morton <akpm@linux-foundation.org>
dlech
pushed a commit
that referenced
this pull request
Sep 23, 2025
Patch series "mm: remove nth_page()", v2. As discussed recently with Linus, nth_page() is just nasty and we would like to remove it. To recap, the reason we currently need nth_page() within a folio is because on some kernel configs (SPARSEMEM without SPARSEMEM_VMEMMAP), the memmap is allocated per memory section. While buddy allocations cannot cross memory section boundaries, hugetlb and dax folios can. So crossing a memory section means that "page++" could do the wrong thing. Instead, nth_page() on these problematic configs always goes from page->pfn, to the go from (++pfn)->page, which is rather nasty. Likely, many people have no idea when nth_page() is required and when it might be dropped. We refer to such problematic PFN ranges and "non-contiguous pages". If we only deal with "contiguous pages", there is not need for nth_page(). Besides that "obvious" folio case, we might end up using nth_page() within CMA allocations (again, could span memory sections), and in one corner case (kfence) when processing memblock allocations (again, could span memory sections). So let's handle all that, add sanity checks, and remove nth_page(). Patch #1 -> #5 : stop making SPARSEMEM_VMEMMAP user-selectable + cleanups Patch #6 -> #13 : disallow folios to have non-contiguous pages Patch #14 -> #20 : remove nth_page() usage within folios Patch #22 : disallow CMA allocations of non-contiguous pages Patch #23 -> #33 : sanity+check + remove nth_page() usage within SG entry Patch #34 : sanity-check + remove nth_page() usage in unpin_user_page_range_dirty_lock() Patch #35 : remove nth_page() in kfence Patch #36 : adjust stale comment regarding nth_page Patch #37 : mm: remove nth_page() A lot of this is inspired from the discussion at [1] between Linus, Jason and me, so cudos to them. This patch (of 37): In an ideal world, we wouldn't have to deal with SPARSEMEM without SPARSEMEM_VMEMMAP, but in particular for 32bit SPARSEMEM_VMEMMAP is considered too costly and consequently not supported. However, if an architecture does support SPARSEMEM with SPARSEMEM_VMEMMAP, let's forbid the user to disable VMEMMAP: just like we already do for arm64, s390 and x86. So if SPARSEMEM_VMEMMAP is supported, don't allow to use SPARSEMEM without SPARSEMEM_VMEMMAP. This implies that the option to not use SPARSEMEM_VMEMMAP will now be gone for loongarch, powerpc, riscv and sparc. All architectures only enable SPARSEMEM_VMEMMAP with 64bit support, so there should not really be a big downside to using the VMEMMAP (quite the contrary). This is a preparation for not supporting (1) folio sizes that exceed a single memory section (2) CMA allocations of non-contiguous page ranges in SPARSEMEM without SPARSEMEM_VMEMMAP configs, whereby we want to limit possible impact as much as possible (e.g., gigantic hugetlb page allocations suddenly fails). Link: https://lkml.kernel.org/r/20250901150359.867252-1-david@redhat.com Link: https://lkml.kernel.org/r/20250901150359.867252-2-david@redhat.com Link: https://lore.kernel.org/all/CAHk-=wiCYfNp4AJLBORU-c7ZyRBUp66W2-Et6cdQ4REx-GyQ_A@mail.gmail.com/T/#u [1] Signed-off-by: David Hildenbrand <david@redhat.com> Acked-by: Zi Yan <ziy@nvidia.com> Acked-by: Mike Rapoport (Microsoft) <rppt@kernel.org> Acked-by: SeongJae Park <sj@kernel.org> Reviewed-by: Wei Yang <richard.weiyang@gmail.com> Reviewed-by: Lorenzo Stoakes <lorenzo.stoakes@oracle.com> Reviewed-by: Liam R. Howlett <Liam.Howlett@oracle.com> Cc: Huacai Chen <chenhuacai@kernel.org> Cc: WANG Xuerui <kernel@xen0n.name> Cc: Madhavan Srinivasan <maddy@linux.ibm.com> Cc: Michael Ellerman <mpe@ellerman.id.au> Cc: Nicholas Piggin <npiggin@gmail.com> Cc: Christophe Leroy <christophe.leroy@csgroup.eu> Cc: Paul Walmsley <paul.walmsley@sifive.com> Cc: Palmer Dabbelt <palmer@dabbelt.com> Cc: Albert Ou <aou@eecs.berkeley.edu> Cc: Alexandre Ghiti <alex@ghiti.fr> Cc: "David S. Miller" <davem@davemloft.net> Cc: Andreas Larsson <andreas@gaisler.com> Cc: Alexander Gordeev <agordeev@linux.ibm.com> Cc: Alexander Potapenko <glider@google.com> Cc: Alexandru Elisei <alexandru.elisei@arm.com> Cc: Alex Dubov <oakad@yahoo.com> Cc: Alex Willamson <alex.williamson@redhat.com> Cc: Bart van Assche <bvanassche@acm.org> Cc: Borislav Betkov <bp@alien8.de> Cc: Brendan Jackman <jackmanb@google.com> Cc: Brett Creeley <brett.creeley@amd.com> Cc: Catalin Marinas <catalin.marinas@arm.com> Cc: Christian Borntraeger <borntraeger@linux.ibm.com> Cc: Christoph Lameter (Ampere) <cl@gentwo.org> Cc: Damien Le Maol <dlemoal@kernel.org> Cc: Dave Airlie <airlied@gmail.com> Cc: Dennis Zhou <dennis@kernel.org> Cc: Dmitriy Vyukov <dvyukov@google.com> Cc: Doug Gilbert <dgilbert@interlog.com> Cc: Heiko Carstens <hca@linux.ibm.com> Cc: Herbert Xu <herbert@gondor.apana.org.au> Cc: Ingo Molnar <mingo@redhat.com> Cc: Inki Dae <m.szyprowski@samsung.com> Cc: James Bottomley <james.bottomley@HansenPartnership.com> Cc: Jani Nikula <jani.nikula@linux.intel.com> Cc: Jason A. Donenfeld <jason@zx2c4.com> Cc: Jason Gunthorpe <jgg@nvidia.com> Cc: Jason Gunthorpe <jgg@ziepe.ca> Cc: Jens Axboe <axboe@kernel.dk> Cc: Jesper Nilsson <jesper.nilsson@axis.com> Cc: Johannes Weiner <hannes@cmpxchg.org> Cc: John Hubbard <jhubbard@nvidia.com> Cc: Jonas Lahtinen <joonas.lahtinen@linux.intel.com> Cc: Kevin Tian <kevin.tian@intel.com> Cc: Lars Persson <lars.persson@axis.com> Cc: Linus Torvalds <torvalds@linux-foundation.org> Cc: Marco Elver <elver@google.com> Cc: "Martin K. Petersen" <martin.petersen@oracle.com> Cc: Maxim Levitky <maximlevitsky@gmail.com> Cc: Michal Hocko <mhocko@suse.com> Cc: Muchun Song <muchun.song@linux.dev> Cc: Niklas Cassel <cassel@kernel.org> Cc: Oscar Salvador <osalvador@suse.de> Cc: Pavel Begunkov <asml.silence@gmail.com> Cc: Peter Xu <peterx@redhat.com> Cc: Robin Murohy <robin.murphy@arm.com> Cc: Rodrigo Vivi <rodrigo.vivi@intel.com> Cc: Shameerali Kolothum Thodi <shameerali.kolothum.thodi@huawei.com> Cc: Shuah Khan <shuah@kernel.org> Cc: Suren Baghdasaryan <surenb@google.com> Cc: Sven Schnelle <svens@linux.ibm.com> Cc: Tejun Heo <tj@kernel.org> Cc: Thomas Bogendoerfer <tsbogend@alpha.franken.de> Cc: Thomas Gleinxer <tglx@linutronix.de> Cc: Tvrtko Ursulin <tursulin@ursulin.net> Cc: Ulf Hansson <ulf.hansson@linaro.org> Cc: Vasily Gorbik <gor@linux.ibm.com> Cc: Vlastimil Babka <vbabka@suse.cz> Cc: Will Deacon <will@kernel.org> Cc: Yishai Hadas <yishaih@nvidia.com> Signed-off-by: Andrew Morton <akpm@linux-foundation.org>
