border0-router (Border0 Pi)

Border0 Router transforms a Raspberry Pi into a secure Wi-Fi gateway and captive-portal with integrated Border0 VPN. It provides:

• Custom Raspberry Pi OS image build with pre-installed Border0 CLI and Web UI
• Hostapd-based Wi-Fi Access Point and captive portal
• Border0 VPN onboarding: organization setup, authentication, install & start node
• Historical system metrics collection service
• Flask-based Gateway Admin Panel for network, VPN, and system management

Table of Contents

• Features
• Prerequisites
• Quick Start
• First Boot & Access
• Web UI Development
• Customization & Configuration
• Directory Structure
• Troubleshooting

Features

• Automated image build: injects Border0 CLI, Python Web UI, systemd services
• Captive-portal Wi-Fi AP (border0 SSID) with static DHCP/DNS (dnsmasq)
• VPN configuration without shell: full onboarding via Web UI
• Background metrics collector for CPU, memory, disk, network (24 h history)

Prerequisites

Host Machine (build environment)

• Git, Bash, coreutils, curl, sed, xz-utils
• losetup, mount, chroot, qemu-user-static (for ARM64 chroot)
• Make (optional): Makefile provides shortcuts (make download-iso, make build-iso)
• Raspberry Pi Imager (Linux, macOS, Windows) for flashing SD cards
  • Download from: https://www.raspberrypi.com/software/
  • On Debian/Ubuntu: sudo apt update && sudo apt install rpi-imager
  • On Ubuntu (snap): sudo snap install rpi-imager

Raspberry Pi (target device)

• Raspberry Pi 3B+ or newer
• microSD card (≥ 8 GB), power supply
• Ethernet or Wi-Fi client device for connecting to Admin Panel

Quick Start

Click here to watch the installation guide

First Boot & Access

1. Insert the SD card into your Raspberry Pi and power it on.
2. The device will provision services (hostapd, dnsmasq, Border0 CLI, Web UI) and reboot.
3. Connect a client to the border0 Wi-Fi SSID.
4. In your browser, navigate to http://gateway.border0 or http://10.10.10.10 or follow the captive portal.
5. Log in with your Border0 Account credentials.
6. Configure network interfaces, Border0 VPN(exit-node), view metrics, reboot, upgrade.

Build the Image and Develop locally

1. Clone the repo:

   git clone https://github.com/borderzero/border0-router.git
   cd border0-router

2. Download the stock Raspberry Pi OS ARM64 Lite image:

   make download-iso

3. Build the custom Border0 image (requires sudo for loop mounts):

   sudo make build-iso

   • To generate a compressed .img.xz, prefix with CREATE_XZ=true:

     sudo CREATE_XZ=true make build-iso

4. Flash to microSD using Raspberry Pi Imager:

   1. Launch Imager, click CHOOSE OS → Use custom, select iso/*-border0-*.img
   2. Click CHOOSE STORAGE, select your SD card
   3. Click WRITE and wait for completion

   Or use dd:

   sudo dd if=$(ls iso/*-border0-*.img | head -1) of=/dev/sdX bs=4M conv=fsync status=progress
   ```</small>



Web UI Development

cd webui
./setup.sh        # create venv, install Python deps
source venv/bin/activate
./run.sh          # launch dev server

• Access at http://localhost:5000
• Python code under webui/gateway_admin/, static templates under webui/static/.

Customization & Configuration

• Override defaults via environment variables:

  export ADMIN_USERNAME=myadmin
  export ADMIN_PASSWORD=mysecurepass
  export SECRET_KEY=$(openssl rand -hex 16)

• To adjust build packages, edit EXTRA_PKGS and REMOVE_PKGS in build/build_iso.sh.

• To override the default LAN/WAN interfaces baked into the image, set the environment variables before building:

  export DEFAULT_LAN_IFACE=eth1
  export DEFAULT_WAN_IFACE=eth0
  sudo make build-iso

Directory Structure

. ├── build        # Image build scripts & systemd templates
    ├── download_iso.sh
    ├── build_iso.sh
    └── templates
  ├── iso          # Stock & custom Raspberry Pi OS images
  ├── webui        # Flask admin panel & assets
  ├── requirements.txt
  └── Makefile     # Build & deploy shortcuts

Troubleshooting

• Missing qemu-user-static: sudo apt install qemu-user-static
• Permission denied mounting loop devices: rerun build with sudo
• Web UI unreachable: check border0-webui status:

  sudo systemctl status border0-webui

License

This project is licensed under the Apache License, Version 2.0. See the LICENSE file for details.
