Add source-index build job to pipeline #37028

dougbu · 2021-09-27T19:05:33Z

Add source index build step #33534
use 1ES agents because default VS is incompatible with our .NET SDK version
- windows-latest might work but prefer to protect binary log
wait to source-index for other jobs
use binary log from Linux_x64 build
- we're waiting for that build anyhow
only source index the 'main' branch
- anything else would be redundant

nits:

remove unnecessary backslashes in the Linux_x64_build job's scripts
- instead separate commands with a semicolon
confirm test build success before BAR updates in manual builds

.azure/pipelines/ci.yml

wtgodbe · 2021-09-27T19:09:37Z

.azure/pipelines/ci.yml

This list is a little spooky, it seems likely people won't know to update it if/when our set of jobs changes

Been this way forever unfortunately. AzDO schema doesn't provide a way to automagically wait for almost every other job.

Main mitigation is @dotnet/aspnet-build are automagically reviewers whenever a .azure/ file is changed.

wtgodbe

LGTM other than the comment

dougbu · 2021-09-27T19:23:01Z

Fortunately, my typo was in the last commit and didn't invalidate internal build 20210927.7

dougbu · 2021-09-27T20:38:06Z

New internal (real test) build is 20210927.10

.azure/pipelines/ci.yml

dougbu · 2021-09-28T03:54:39Z

Sorry to those playing along for squashing all prior commits on you.

New test build is 20210927.27

davidfowl · 2021-09-28T16:53:53Z

This link is currently broken on http://source.dot.net

dougbu · 2021-09-28T20:45:27Z

The approach of using a binary log from another job isn't going to work at all. The processing seems to require generated files.

Unhandled exception. System.IO.DirectoryNotFoundException: Could not find a part of the path 'D:\a\_work\1\s\artifacts\obj\Microsoft.Extensions.Caching.SqlServer\Release\net7.0\.NETCoreApp,Version=v7.0.AssemblyAttributes.cs'.

My main idea is to build and process the binary log in one job then do the "Upload stage1 artifacts to source index" part using a new artifact from the first job (after the rest of the build completes successfully). The main downside will be not keeping us up-to-date w/ eng/common/templates/job/source-index-stage1.yml. Ideal would be a step template or two from Arcade that installs and runs BinLogToSln (no need for UseDotNet@2 or UploadIndexStage1 there) and another job or step template containing the UploadIndexStage1 part. But, I could copy the bits and pieces over for now.

Thoughts @alexperovich @davidfowl @wtgodbe❔ Other suggestions❔

alexperovich · 2021-09-28T21:37:31Z

would this just be downloading a new artifact from the first build? Would the preSteps parameter not work for this?

dougbu · 2021-09-28T21:44:19Z

would this just be downloading a new artifact from the first build? Would the preSteps parameter not work for this?

Since there's no reason not to proactively run BinLogToSln, my thought was to do that in the first job (together w/ a regular build) then only run UploadIndexStage1 later, after everything else succeeds.

Just using preSteps would require a new artifact containing at least all artifacts/**/*.cs. That wouldn't be too gigantic an artifact but I'm not sure how many other types of files we'd need nor whether we would need generated files from elsewhere in the sources directory.

dougbu · 2021-09-29T17:07:53Z

Have the C# upload / download working now, I hope. Latest test build is https://dev.azure.com/dnceng/internal/_build/results?buildId=1393133&view=results

This time, the exact internal build commit is present here on GitHub too. I just added the main-branch-only commit here. That should help your checks @davidfowl (assuming the test build works).

.azure/pipelines/ci.yml

dougbu · 2021-09-29T17:16:58Z

.azure/pipelines/jobs/default-build.yml

The key word here is "runtime" i.e. the value of artifact.path for the Windows_arm_csharp artifact is $(Build.ArtifactStagingDirectory), not e.g. D:\a\_work\1\a.

.azure/pipelines/ci.yml

alexperovich · 2021-09-29T20:58:18Z

I don't have a problem with running BinLogToSln in a separate job, I can update the code in arcade once we get a design that works for aspnetcore.

- #33534 - start source indexing after other jobs - do not update https://source.dot.net/ from failed builds - use 1ES agents - `windows-latest` might work but prefer to protect binary log - use Windows_arm_build binary log - align binary log with source-indexing agent i.e. always use Windows - much faster than Windows x64/x86 build - provide another binary log, even in internal builds nits: - remove unnecessary backslashes in the Linux_x64_build job's `script`s - instead separate commands with a semicolon - confirm test build success before BAR updates in manual builds - merge a couple of `in(...)` expressions

- required for source-indexing from the binary log

- this approach is taking us down a rabbit hole This reverts commit 033ba5696bbc545538bcf9172825a70e5e7bff49.

- this approach is taking us down a rabbit hole This reverts commit 6426a6195972dc778de4552eb70a978f1ed57adf.

- current template not well suited to reuse a binary log from another job

dougbu · 2021-10-02T04:41:00Z

Very different than previous iterations but working 🎉 Build 20211001.17 was successful and uploaded what looks like a complete set of sources.

Due to how I organized the template expressions, the commits here are identical. https://source.dot.net/ should have no broken links. But, right now, it's using the now-lost commit from my first (prototype) successful run.

dougbu · 2021-10-02T04:48:25Z

.azure/pipelines/ci.yml

+- name: testSourceIndexing
+  default: false
+  displayName: Test source indexing? !Danger! see comments in YAML.
+  type: boolean


This parameter is visible in the AzDO UI but, as mentioned in the comments, ignored in public builds.

.azure/pipelines/ci.yml

dougbu · 2021-10-04T02:29:10Z

@alexperovich, @wtgodbe is OOF now. I'd appreciate you double-checking this PR before I merge it. Thanks…
