EmbedThis Updater

The EmbedThis Updater is a secure, lightweight command-line utility and library for downloading and applying device software updates published on the EmbedThis Builder.

Security for Devices

The European Union has introduced the Cyber Resilience Act (CRA), a regulation aimed at enhancing cybersecurity for IoT products. This legislation mandates that manufacturers ensure their products are secure throughout their entire lifecycle, from design to decommissioning. This requires that software updates are provided for the lifetime of the device.

To meet this need, the Updater can be used to automatically download and apply software updates to all your connected devices.

Description

Devices can use the updater command or library to enable Over-The-Air (OTA) software update capabilities. The EmbedThis Builder cloud service provides:

Update Management:

• Secure hosting on AWS S3 with global CDN distribution
• Upload and manage software update images
• SemVer 2.0 compatible version management
• SHA-256 checksum validation
• HTTPS-only secure downloads

Selective Distribution:

• JavaScript-like distribution policy expressions
• Target updates based on device properties, versions, or custom criteria
• Opt-in update mechanism (devices request updates)
• Version comparison and compatibility checking

Rollout Control:

• Gradual rollout with percentage-based limits
• Maximum updates per time period throttling
• Update rate control to minimize service load
• Ability to defer or rollback updates

Monitoring & Analytics:

Using the EmbedThis Builder cloud service, you can publish, distribute, monitor and analyze update metrics and reporting.

• View real-time update metrics and reporting via the Builder Portal
• Track successful, failed, and deferred updates
• Analyze per-product and per-version update metrics

The Builder cloud service stores and distributes update packages to devices using a secure, global CDN. The Builder update policies are evaluated per device so you can target updates to specific devices, device groups, or device properties.

The updater client works by periodically checking in with the Builder cloud service. The cloud evaluates the software update distribution policy and returns an update URL if the device qualifies. The updater then downloads, verifies, and applies the update.

Learn More:

• Builder Documentation - Complete Builder platform documentation
• Software Update Guide - Detailed update workflow and features
• Design Document - Architecture and implementation details

Variants

This repository provides multiple implementations of a standalone updater program:

• C implementation - Production-ready command line utility and library with minimal dependencies
• NodeJS/Bun implementation - JavaScript alternative
• Shell script sample - Documentation/reference implementation (not for production use)

All implementations include:

• HTTPS enforcement
• Certificate validation
• Checksum verification (SHA-256)
• Content-Length validation
• Timeout protection
• Secure file handling

Device Agents

The Ioto device agent includes the updater functionality internally. The Appweb and GoAhead web servers include this repository under their src/updater directories.

All devices using other embedded web servers and device agents can include this Updater to add OTA software update functionality.

Updater Command

updater [options] key=value,...

Where options are:

Option	Description
--cmd script	Script to invoke to apply the update
--device ID	Unique device ID
--file image/path	Path to save the downloaded update (default: update.bin)
--host host.domain	Device cloud endpoint from the Builder cloud edit panel
--product ProductID	ProductID from the Builder token list
--token TokenID	CloudAPI access token from the Builder token list
--version SemVer	Current device firmware version
--verbose, -v	Trace execution

The key=value pairs can provide device specific properties that can be used by the Builder software update policy to determine which devices receive the update.

Example:

updater -v --device "A123456789" \
    --host "https://ygp2t8ckqj.execute-api.ap-southeast-1.amazonaws.com" \
    --product "XABCDACC2T1234567890123455" \
    --token "TT488ETG5H1234567890123456" \
    --version "2.1.2" \
    --cmd ./apply.sh \
    pro=true

Replace the host, product and token with values from your Builder account.

Library

You can integrate the updater as a library in your C/C++ programs:

#include "updater.h"

int update(cchar *host, cchar *product, cchar *token, cchar *device,
           cchar *version, cchar *properties, cchar *path, cchar *script,
           int verbose);

The update() function performs a complete OTA update cycle:

1. Checks for available updates from the Builder service
2. Downloads the update package if available
3. Verifies the SHA-256 checksum
4. Executes the specified script to apply the update
5. Reports update status back to Builder

Parameters:

• host - Builder cloud endpoint URL
• product - Product ID from Builder token list
• token - CloudAPI access token
• device - Unique device identifier
• version - Current firmware version
• properties - JSON string of device properties (can be NULL)
• path - Local path to save downloaded update
• script - Path to script that applies the update (can be NULL to skip application)
• verbose - Enable verbose logging (0 or 1)

Returns: 0 on success, -1 on error

Building

C Implementation

make                # Build updater program
make clean          # Clean build artifacts

Requirements:

• GCC or compatible C compiler
• OpenSSL or LibreSSL development libraries
• Make

Node.js/Bun Implementation

The JavaScript version requires Node.js 18+ or Bun and has no additional dependencies:

node src/updater.js [options]
# or
bun src/updater.js [options]

Shell Script Implementation

The shell script implementation requires no additional dependencies:

./src/updater.sh [options]

Tests

The test suite is located in the test/ directory and uses the TestMe framework.

The test suite requires the following prerequisites:

• Bun: v1.2.23 or later
• TestMe: Test runner (installed globally)

Install Bun by following the instructions at:

https://bun.com/docs/installation

Install TestMe globally with:

bun install -g --trust @embedthis/testme

Run the tests with:

make test

or manually via the tm command.

tm

To run a specific test or group of tests, use the tm command with the test name.

tm NAME

Security Features

All implementations provide robust security:

• HTTPS Only - Enforces HTTPS for all network communication
• Certificate Validation - Validates server certificates against system CA bundle
• Checksum Verification - SHA-256 checksum validation of downloaded updates
• Content-Length Validation - Validates and enforces size limits (100MB max)
• Timeout Protection - Network and script execution timeouts prevent hanging
• Secure File Handling - Exclusive file creation with restricted permissions (0600)
• Input Validation - Validates all inputs and API responses
• Error Handling - Comprehensive error checking and reporting

Files

File	Description
C Implementation
Makefile	Build configuration for C updater
main.c	Command-line interface for C updater
updater.c	Core update library implementation
updater.h	Public API header
JavaScript Implementation
src/updater.js	Node.js/Bun command-line updater
Shell Script Implementation
src/updater.sh	Shell script sample utility
Supporting Files
apply.sh	Sample update application script
README.md	This documentation

Repository

You can find the source for the updater at https://github.com/embedthis/updater.
