Vector — Roblox Studio Copilot

A Roblox Studio AI copilot with a Next.js backend and an LLM tool-calling orchestrator, designed to mirror Cline's step-by-step tool usage, context management, and diff-first editing. Vector enables safe, undoable changes to Roblox places through a docked chat UI in Studio, with proposals for edits, instance operations, and asset integrations. Watch the demo

Overview

  • Studio Plugin (Luau): Provides a docked chat interface, reads active editor state, previews diffs, and applies edits inside Roblox's ChangeHistoryService. It communicates with the backend for LLM orchestration.
  • Next.js Backend (TypeScript): Handles API endpoints for chat, streaming, proposals, and asset search/generation. Orchestrates LLM tool calls with a deterministic, proposal-first workflow.
  • LLM Tool-Calling: One-tool-per-message, approval-first (like Cline). The model proposes changes; only the plugin applies them after user approval. Supports providers like OpenRouter and Gemini.
  • Key Features:
    • Diff previews and safe edits with undo support.
    • Instance creation, property setting, renaming, and deletion.
    • Asset Store integration (search and insert from Roblox Catalog).
    • 3D generation via Meshy API.
    • Streaming status updates and multi-turn conversations.
    • Context gathering (active script, selection, open documents).
    • Audit logging and persistence for proposals and workflows.

Architecture

Vector follows a runtime split: the backend (Next.js on Vercel or local) handles planning, LLM calls, and tool orchestration; the Studio plugin (Luau) reads context, previews changes, and performs writes with undo/redo. All mutations are wrapped in ChangeHistoryService for safety.

High-Level Components

  • Backend (Next.js): API routes, orchestrator, tool schemas, providers, data stores.
  • Plugin (Luau): UI, network helpers, tool handlers for Roblox APIs.
  • Data Flow: User input → Context gathering → LLM tool call → Proposal generation → Approval → Apply with undo → Audit.

Mermaid Diagram: System Architecture and Data Flow

flowchart TD
    %% User and Studio Plugin
    subgraph Studio_Plugin["Roblox Studio Plugin (Luau)"]
        UI[Chat UI + Composer] --> ContextCollector["Context Collector<br/>(Active Script, Selection)"]
        ContextCollector --> ChatAPI["/api/chat POST"]
        ChatAPI --> ProposalRenderer["Proposal Renderer<br/>(Diffs/Ops Preview)"]
        ProposalRenderer --> ApprovalGate{User Approves?}
        ApprovalGate -- Yes --> ToolExecutor["Tool Executor<br/>(Apply Edit / Insert Asset)"]
        ToolExecutor --> ChangeHistory["ChangeHistoryService<br/>(Undo Step)"]
        ChangeHistory --> ApplyAPI["/api/proposals/:id/apply POST"]
        ApprovalGate -- No --> Reject[Reject Proposal]
        StreamPoller["/api/stream Long-Poll"] --> StatusUI["Status Panel<br/>(Streaming Updates)"]
    end

    %% Backend and Orchestrator
    subgraph Backend["Next.js Backend (TypeScript)"]
        ChatAPI --> Orchestrator[LLM Orchestrator]
        Orchestrator --> SystemPrompt[System Prompt + Tool Registry]
        SystemPrompt --> LLM["LLM Provider<br/>(OpenRouter / Gemini)"]
        LLM --> ToolParser[Tool Call Parser]
        ToolParser --> ProposalBuilder["Proposal Builder<br/>(Edits / Object Ops / Asset Ops)"]
        ProposalBuilder --> ChatAPI
        ProposalBuilder --> ProposalsStore[("Proposals Store<br/>(JSON / DB)")]
        ApplyAPI --> ProposalsStore
        StreamPoller --> StreamBus["Stream Bus<br/>(Events: Tool Results, Errors)"]
        StreamBus --> StatusUI
        AssetSearchAPI["/api/assets/search GET"] --> CatalogProvider["Catalog Provider<br/>(Roblox API / Stub)"]
        CatalogProvider --> Orchestrator
        Generate3DAPI["/api/assets/generate3d POST"] --> MeshyAPI["Meshy API<br/>(Text-to-3D)"]
        MeshyAPI --> OpenCloud["Roblox Open Cloud<br/>(Asset Upload)"]
        OpenCloud --> Orchestrator
    end

    %% Context and Memory
    subgraph Context_Memory["Context and Memory"]
        Orchestrator --> ContextManager["Context Manager<br/>(Token Tracking, Summarization)"]
        ContextManager --> ToolCache[("Tool Result Cache<br/>(Fingerprints + TTL)")]
        ToolCache --> Orchestrator
        ProposalsStore --> WorkflowLedger[("Workflow Ledger<br/>(Steps, Fingerprints, Audit)")]
        WorkflowLedger --> ContextManager
    end

    %% Links
    UserInput[User Input] --> UI
    ToolExecutor --> WorkflowLedger
    LLM --> StreamBus
    ContextCollector --> ContextManager

    %% Notes as side nodes (valid on GitHub)
    ApprovalGate -.-> Note1["📌 Approval required for all writes<br/>One undo step per apply"]:::note
    Orchestrator -.-> Note2["📌 One tool per LLM message<br/>Deterministic fallbacks on errors"]:::note
    StreamBus -.-> Note3["📌 Long-poll for Studio<br/>SSE for dashboards"]:::note

    %% Styles
    classDef note fill:#f5f5f7,stroke:#c7c7cc,color:#111,stroke-width:1px,font-style:italic;
Loading

This diagram illustrates the core data flow, runtime components, and integrations. The plugin handles UI and Roblox writes; the backend manages LLM orchestration, asset search/generation, and persistence.

Features in Detail

1. Editing Workflow (Diff-First, Approval-First)

  • Preview: LLM proposes edits via show_diff; plugin renders unified diffs.
  • Apply: On approval, apply_edit runs with ChangeHistoryService for undo support.
  • Safety: beforeHash validation prevents conflicts; edits are sorted, non-overlapping, and capped (≤20 edits, ≤2000 chars).
  • Multi-File: Server-side diff3 merging with conflict detection.

2. Instance Operations

  • create_instance, set_properties, rename_instance, delete_instance.
  • Selection inference: Defaults to selected instance if not specified.
  • All wrapped in ChangeHistoryService for single undo steps.

3. Asset Store Integration

  • search_assets: Queries Roblox Catalog (real API or stubs).
  • insert_asset: Inserts by ID and optionally configures via set_properties.
  • 3D Generation: generate_asset_3d proxies to Meshy API → Open Cloud upload.

4. Context Gathering

  • Plugin: Reads active script, selection, open documents.
  • Backend: Tools like get_active_script, list_selection, list_open_documents.
  • Mentions: Supports @file, @folder, @url, @problems for attachments.
  • Caching: Tool results cached with fingerprints to avoid re-reading unchanged code.

5. Streaming and Multi-Turn Conversations

  • Plan/Act Modes: Multi-turn loops with context tools executed locally.
  • Streaming: Long-poll (/api/stream) for Studio; SSE (/api/stream/sse) for dashboards.
  • Status: Real-time updates via event bus (e.g., tool results, errors).
  • Memory: Workflow ledger tracks steps; auto-compaction when near token limits.

6. Safety and Permissions

  • Permissions: First-time HTTP and Script Modification prompts in Studio.
  • Audit: Proposals, applies, and outcomes logged.
  • Guardrails: Deterministic fallbacks; no broad rewrites without approval.

Installation and Setup

Prerequisites

  • Node.js 18+ for the backend.
  • Roblox Studio for the plugin.
  • Optional: Rojo for plugin syncing during dev.

Backend (Next.js)

  1. Navigate to vector/apps/web:
    cd vector/apps/web
npm install
  2. Configure .env.local (already added):
    • OPENROUTER_API_KEY= (for OpenRouter provider; leave blank for fallbacks).
    • OPENROUTER_MODEL=moonshotai/kimi-k2:free.
    • VECTOR_USE_OPENROUTER=0 (set to 1 to enable).
    • VECTOR_DEFAULT_PROVIDER=openrouter (or gemini).
    • GEMINI_API_KEY= (for direct Gemini calls).
    • CATALOG_API_URL= (for real catalog search; optional).
    • MESHY_API_KEY= (for 3D generation; optional).
  3. Run:
    npm run dev  # Listens on http://127.0.0.1:3000
    • Data persists in vector/apps/web/data/ (auto-created).

Plugin (Studio)

  1. Load the plugin source at vector/plugin/src (via Rojo or manual install).
  2. No settings needed; backend uses .env.local.
  3. Open Vector dock in Studio. First request prompts HTTP permission; first write prompts Script Modification.

Quick Checks

  • GET /api/assets/search?query=test&limit=3 → Returns stub items if no catalog API.
  • POST /api/assets/generate3d with {"prompt":"cube"} → Returns jobId.

Implementation Status

Based on IMPLEMENTATION_STATUS.md:

Implemented

  • Core Orchestrator: Tool-call parsing, proposals, fallbacks, streaming.
  • APIs: /api/chat, /api/proposals, /api/stream, /api/assets/search, /api/assets/generate3d.
  • Plugin Tools: Context gathering, edits, instance ops, asset insertion.
  • UI: Chat, diff previews, approval flow, Auto mode.
  • Persistence: File-backed proposals, workflows, audit.

Partially Implemented

  • list_open_documents: Event-driven but falls back on legacy.
  • generate_asset_3d: Stub jobId; no full GPU pipeline.
  • Asset Catalog: Stubs if CATALOG_API_URL unset.
  • Workflows: File-backed; no DB yet.

Not Implemented

  • Advanced UI (slash commands, thumbnails proxy).
  • Conversation summarization.
  • Analysis/CI tools.
  • Durable DB (still JSON files).

See IMPLEMENTATION_STATUS.md for full details and needs (e.g., provider credentials, catalog API).

Usage

  1. Start Backend: Run npm run dev in vector/apps/web.
  2. Open Studio: Load plugin, open Vector dock.
  3. Chat: Type a prompt (e.g., "Create a 3x3 grid of parts"). Select Ask/Agent mode.
  4. Proposals: Review diffs/ops, approve to apply.
  5. Auto Mode: Toggle on for unattended applies (bounded steps).
  6. Streaming: Watch status panel for progress.
  7. Undo: Use Studio's undo for any applied changes.

Testing

Vector includes a comprehensive automated testing framework for the agent's capabilities. The testing framework simulates Roblox Studio in a virtual environment, allowing you to test the agent's tool usage and behavior without manual intervention.

Quick Start

# Navigate to backend
cd vector/apps/web

# Run all tests with verbose output
npm run test:agent:verbose

# Generate JSON and HTML reports
npm run test:agent:reports

# Run only tool tests
npm run test:agent -- --only=tool

# Run only scenario tests
npm run test:agent -- --only=scenario

# Run specific tests
npm run test:agent -- --only=create_instance,set_properties

What Gets Tested

The test suite includes:

Individual Tool Tests (1 test):

  • Basic instance creation to verify API integration works

Scenario Tests (7 real-world tests):

Intelligence & Reasoning:

  • Create Blinking Part: Planning, script policy, code quality (loops, Color3, idempotency)
  • Simple Part Creation: Script policy enforcement (must write Luau even for simple geometry)
  • Build Watch Tower: Asset-first approach (prefer search_assets over manual geometry)
  • Avoid Duplicate Creation: Scene inspection before creating duplicates

Geometry Quality:

  • Build Simple House Structure: Multi-part structures, anchoring, sizing, materials, CFrame positioning
  • Create Aligned Part Grid: Precise positioning, spacing, alignment, loops for efficiency
  • Build Ramp or Stairs: Rotation with CFrame.Angles, WedgeParts, incremental positioning

Test Reports

The framework generates three types of output:

  1. Terminal Output: Real-time test execution with pass/fail indicators and summary statistics
  2. JSON Report: Machine-readable results in test-results/test-results.json for CI/CD integration
  3. HTML Report: Beautiful interactive report in test-results/test-results.html with expandable details

How It Works

  1. Virtual Environment: Creates an in-memory simulation of Roblox Studio with a file system and instance hierarchy
  2. Agent Executor: Connects to the real /api/chat endpoint with your configured LLM provider
  3. Auto-Approval: Automatically approves and applies all proposals to the virtual environment
  4. Verification: Uses two approaches:
    • Programmatic Checks: Verifies tool usage, state changes, and specific code patterns
    • AI Review (optional): GPT-5 Nano evaluates code quality, idempotency, and adherence to best practices
  5. Detailed Logging: Captures all tool calls, state changes, and performance metrics

Requirements

  • Backend running on http://localhost:3000 (or configure with --base-url)
  • API key in .env.local for agent execution (ANTHROPIC_API_KEY or OPENAI_API_KEY)
  • Optional: REVIEWER_OPENAI_API_KEY in .env.local to enable AI review for intelligence tests
  • All dependencies installed (npm install)

Documentation

For complete documentation on the testing framework, including architecture details and how to add new tests, see:

  • vector/apps/web/lib/testing/AGENT_TESTING_GUIDE.md - Complete testing guide (start here!)
  • vector/apps/web/lib/testing/tests/scenario-tests.ts - All test definitions (8 scenarios)
  • TESTING_FRAMEWORK_REVIEW.md - Technical implementation notes

Contributing

  • Linting: Run npm run lint (ESLint, max-warnings=0).
  • Building: npm run build in backend.
  • Testing: Run npm run test:agent before submitting changes to verify agent behavior.
  • Docs: Update Vector.md and IMPLEMENTATION_STATUS.md.
  • Issues: Report via Git; focus on safety, UX, and provider integrations.

Notes and Limitations

  • Local Dev: Assumes http://127.0.0.1:3000; configure for deploys.
  • Providers: OpenRouter default; add Gemini for alternatives.
  • Assets: Real catalog requires API; 3D gen is stubbed.
  • Performance: Caches reduce re-reads; streaming via long-poll.
  • Safety: All writes auditable and reversible.

For more details, see Vector.md (full spec) and IMPLEMENTATION_STATUS.md (progress tracking).
