refactor(experimental): add generic createJsonRpcApi function for custom APIs

[buffalojoec]

This PR is a concept for now. It serves to potentially address the discussion raised in #1740.

The goal of the collective @solana/rpc-* packages has been to allow complete customization, as long as their API adheres to the official JSON RPC spec.

However, I couldn't find the best way someone would actually go about doing this with our current implementation. Maybe I'm missing something.

In the actual library package, we're providing what's been dubbed the "default" Solana API. The function createSolanaRpc(..) allows you to provide your own transport, but it automatically uses the Solana RPC API, defined by @solana/rpc-core for the client API.

solana-web3.js/packages/library/src/rpc.ts

Lines 19 to 24 in 589c379

	export function createSolanaRpc(config: Omit<Parameters<typeof createJsonRpc>[0], 'api'>): Rpc<SolanaRpcMethods> {
	return createJsonRpc({
	...config,
	api: createSolanaRpcApi(DEFAULT_RPC_CONFIG),
	});
	}

If one wants to create their own RPC client manually, they can use the following code, comprised of @solana/rpc-transport and @solana/rpc-core, not the main library.

const api = createSolanaRpcApi();
    // ^ IRpcApi<SolanaRpcMethods>

const transport = createHttpTransport({ url: 'http://127.0.0.1:8899' });

const rpc = createJsonRpc<SolanaRpcMethods>({ api, transport });
    // ^ RpcMethods<SolanaRpcMethods>

You can see you can choose to define your API and provide it as a parameter to createJsonRpc(..), however unless I'm missing something in our code, there's no generic API-creator.

This PR attempts to roll that generic API-creator as createJsonRpcApi(..).

I envision this function being extremely useful for projects who wish to define their own rpc-core type-spec via interfaces, as we have with SolanaRpcMethods, and simply create it like so:

// Define the method's response payload
type NftCollectionDetailsApiResponse = Readonly<{
    address: string;
    circulatingSupply: number;
    description: string;
    erc721: boolean;
    erc1155: boolean;
    genesisBlock: string;
    genesisTransaction: string;
    name: string;
    totalSupply: number;
}>;

// Set up an interface for the request method
interface NftCollectionDetailsApi {
    // Define the method's name, parameters and response type
    qn_fetchNFTCollectionDetails(args: { contracts: string[] }): NftCollectionDetailsApiResponse;
}

// Export the type spec for downstream users
export type QuickNodeRpcMethods = NftCollectionDetailsApi;

// Create the custom API
const api = createJsonRpcApi<QuickNodeRpcMethods>();

// Set up an HTTP transport
const transport = createHttpTransport({ url: 'http://127.0.0.1:8899' });

// Create the RPC client
const quickNodeRpc = createJsonRpc<QuickNodeRpcMethods>({ api, transport });
       // ^ RpcMethods<QuickNodeRpcMethods>

Of course you could also combine your type spec with Solana's:

export type QuickNodeSolanaRpcMethods = SolanaRpcMethods & NftCollectionDetailsApi;

Let me know any thoughts.

[buffalojoec]

Current dependencies on/for this PR:

• master
  • PR refactor(experimental): make RPC methods extend IRpcApiMethods #1843
    • PR refactor(experimental): rename *Processor to *Transformer #1846
      • PR refactor(experimental): add generic createJsonRpcApi function for custom APIs #1781 👈
        • PR refactor(experimental): make RPC subscription methods extend IRpcSubscriptionsApiMethods #1844
          • PR refactor(experimental): add generic createJsonRpcSubscriptionsApi for custom APIs #1845

This stack of pull requests is managed by Graphite.

[steveluscher]

Hmm… interesting.

Backing way up, the point of the IRpcApi type is to say: ‘hey, if you wanna define an API for some JSON RPC, then give me something that conforms to this type’

(...params: WhateverParams[]) => {
    methodName: string;
    params: unknown[];
    responseProcessor?: (response: unknown) => WhateverResponse;
}

One way of doing that is the fancy Proxy solution that I wrote for the Solana JSON-RPC API. That proxy solution works for Solana because all of the methods are conveniently named the same as one would like the JavaScript functions to be, and the params are mostly pass-throughs.

I designed the IRpcApi such that you could write a helper that produced it in some other way, though. In QuickNode's case, for instance, it's very unlikely that they will want to mirror the method names as JavaScript function names.

// I doubt they will want to release this as a JavaScript API
await rpc.qn_fetchNFTCollectionDetails(...).send();

// It's more likely they'll want this
await quickNodeRpc.fetchNFTCollectionDetails(...).send();

They could achieve that by releasing this:

function createQuickNodeRpcApi(): IRpcApi<QuickNodeRpcMethods> {
  return {
    fetchNFTCollectionDetails(...params) {
      return {
        methodName: 'qn_fetchNFTCollectionDetails',
        params,
      }
    },
  };
}

That conforms to the IRpcApi type, and they're good. That's not a great design for an API creator (QuickNode, please don't do that) but it works.

The API creator in this PR adds a layer of indirection without actually letting QuickNode decouple the name of the JavaScript functions and the name of the JSON-RPC methods, so it's handy but maybe not useful.

We could solve this in two ways:

• do nothing and let people make their own API creators (fork ours if they like)
• double down on the ‘API creator in the proxy style’ helper you have here and let people transform the method names too.

[buffalojoec]

We could solve this in two ways:

• do nothing and let people make their own API creators (fork ours if they like)
• double down on the ‘API creator in the proxy style’ helper you have here and let people transform the method names too.

Ok thanks for that insight.

My thinking was that our "here's my API's type spec, now make me an RPC API that conforms to the JSON RPC spec with them" approach was pretty slick. Then people can just fork @solana/rpc-core instead, replace our method types with their own, and plug them all in. IMO that's much easier.

One might think it introduces the idea of it being more restrictive, but if we split out createJsonRpcApi(..) into a generalized API-builder, anyone who doesn't want to use the fancy Proxy setup can just... not. They could do the same thing you've described.

So I guess it comes down to: Should we be nice and de-couple the fancyProxy from our API?

In my opinion, we have absolutely nothing to lose by doing so and we give developers better tooling for creating custom APIs, which is cool.

[buffalojoec]

Backing way up, the point of the IRpcApi type is to say: ‘hey, if you wanna define an API for some JSON RPC, then give me something that conforms to this type’

(...params: WhateverParams[]) => {
    methodName: string;
    params: unknown[];
    responseProcessor?: (response: unknown) => WhateverResponse;
}

I guess one follow-up question is how difficult is it to build an API spec with this the right way, and not use the Proxy stuff?

They could achieve that by releasing this:

function createQuickNodeRpcApi(): IRpcApi<QuickNodeRpcMethods> {
  return {
    fetchNFTCollectionDetails(...params) {
      return {
        methodName: 'qn_fetchNFTCollectionDetails',
        params,
      }
    },
  };
}

This example seems pretty simple tbh haha.

[steveluscher]

Yeah! If we do offer it then we just need to add a method name transformer to the config, so that the method that gets called on the proxy can be different than the method that gets called on the actual RPC. Oh, and then you have to do this all over again for subscriptions, in case folks have custom subscription methods too.

This example seems pretty simple tbh haha.

Yeah, the bad part of the simple example is ‘grows linearly with the number of methods’ whereas the Proxy solution stays the same size with an infinite number of methods.

[buffalojoec]

Oh, and then you have to do this all over again for subscriptions, in case folks have custom subscription methods too.

Yes I anticipated this. 🥞

Yeah! If we do offer it then we just need to add a method name transformer to the config, so that the method that gets called on the proxy can be different than the method that gets called on the actual RPC.

I think it's (the generic API-creator thing) valuable so I'm going to keep going with it & subscriptions. I'll definitely add your suggestions!

[lorisleiva]

• Why wouldn't we provide the entire response to the transformer?
• Would it be possible to wrap the method name, the payload and the URL in a request object so that the entire request can also be provided to the transformer?

[buffalojoec]

• Why wouldn't we provide the entire response to the transformer?

We can, but I think we're only shedding jsonrpc and id.
Check out a response payload in the docs.

• Would it be possible to wrap the method name, the payload and the URL in a request object so that the entire request can also be provided to the transformer?

I believe so, yes!

[lorisleiva]

The reason I'm saying all this is I think this should be comparable to Axios interceptors (or equivalent) where we have no opinion over what could be transformed and we're just like "here's a request I'm about to send, do whatever you want with it" and same with the response. 🙂

[buffalojoec]

So, in my opinion I think createJsonRpcApi(..) should be designed to create APIs that adhere to the JSON RPC spec, without deviation. So, to me, it makes sense to leave part of the request and response unchanged, since modifying request.parameters or response.result still adheres to the JSON RPC interface.

It seems like you probably have the Helius example in mind from #1740 but here, I think this function would not be used to implement the custom transport you referenced there. What do you think?

[lorisleiva]

Yeah that's a fair point actually. So you're allowing the library to transform anything that can be transformed without affecting the JSON RPC specs. I like it!

Am I right to say that, in order to support a urlTransformer on the API side, we would need something like a requestTransformer on the Transport side? Similarly to the responseTransformer, the requestTransformer would only allow you to edit the components of the requests that don't affect the JSON RPC specs. Namely, the parameters and the URL.

[buffalojoec]

Am I right to say that, in order to support a urlTransformer on the API side, we would need something like a requestTransformer on the Transport side? Similarly to the responseTransformer, the requestTransformer would only allow you to edit the components of the requests that don't affect the JSON RPC specs. Namely, the parameters and the URL.

We could do this in theory, but I can't decide if I think it's something we should support.

Are you thinking you'd be able to plug in a requestTransformer that, for example, takes all of the parameters and the method name from the POST body and maps them to URL parameters?

As an aside, I'm also not sure if the Helius endpoints for example are GETs instead of POSTs.

[lorisleiva]

Yeah that's what I'm thinking. I guess it all depends what is technically valid in the JSON RPC specs. Is it okay to use dynamic URLs? Is it okay to use different HTTP methods? If not, then maybe we shouldn't mess with it. If it is valid according to the specs though, then I strongly believe we should offer that level of flexibility.

[buffalojoec]

I can't see anything in the spec that says definitively one way or the other. But it does seem like the intention is a request body.

[steveluscher]

[buffalojoec]

Merge activity

• Dec 11, 8:31 PM: @@buffalojoec started a stack merge that includes this pull request via Graphite.
• Dec 11, 8:33 PM: Graphite rebased this pull request as part of a merge.
• Dec 11, 8:34 PM: @@buffalojoec merged this pull request with Graphite.

[github-actions]

Because there has been no activity on this PR for 14 days since it was merged, it has been automatically locked. Please open a new issue if it requires a follow up.
